ATEN 4-Port VGA Input Board for VM1600 / VM3200

Part No:

VM7104-AT

Price Locked for 30 Days:
Lock Added: N/A
exc VAT
£714.76
£857.71
inc VAT
Full Product Specs
Save 5% - First order discount - Any product - Any price*
Use Promo Code: FIRST5
*This promotion may only be used once, 5% discount is applied to your first order. Can not be used in-conjunction with any other offers. Not available if paying with PayPal.

This item is currently unavailable for next day delivery, however you may still order this item as a back-order?.

4 port VGA Input Board

Available on back-order

Non-Returnable*

Safe & Secure shopping

*This item is non-returnable and non-cancellable due to customisation or built to order.

SKU: VM7104-AT Category:

Can't find what your looking for?

Our qualified I.T. experts are here & ready to help.

Contact us on 0203 617 7663 or email us directly
Aten

Related products

Description

The VM7104 4-Port VGA Input Board offers an easy way to route 4 VGA video and audio sources up to 16 displays, when used in combination with the ATEN Modular Matrix Switch. The VM7104 supports RGBHV / RGBS/ Y CbCr/ YPbPr input signals; stereo audio that can be embedded into HDMI Audio output. The board is built with a hot-swappable design that is compatible with the VM1600, so that the unit doesn’t need to be powered off when the board is changed.

– Connects up to 4 VGA or Component inputs
– Supports RGBHV / RGBS/ YCbCr/ YPbPr input signals
– Hot-swappable design for easy integration of I/O boards
– Compatible with the VM1600 and can be mixed with any modular output boards for optimum flexibilit

Feature Feature Value
Video port type VGA
VGA (D-Sub) ports quantity 4
Material Metal
Product colour Black, Green
Supported graphics resolutions 1920 x 1200 (WUXGA)
Bandwidth 300 MHz
Maximum resolution 1920 x 1200 pixels
Power consumption (typical) 7.1 W
Width 328 mm
Height 228 mm
Weight 560 g
Length 352 mm
Manual Yes
Operating temperature (T-T) 0 – 40 °C
Storage temperature (T-T) -20 – 60 °C
Operating relative humidity (H-H) 0 – 80%

Additional information

Video port type

VGA
Material

Metal
Maximum resolution

1920 x 1200 pixels
Width

328 mm
Weight

560 g
Manual

Yes
Storage temperature (T-T)

-20 – 60 °C
VGA (D-Sub) ports quantity

4
Product colour

Black, Green
Bandwidth

300 MHz
Power consumption (typical)

7.1 W
Height

228 mm
Length

352 mm
Operating temperature (T-T)

0 – 40 °C

Brand

Aten
