Description
Versatile Outdoor Display Fit for Your Business
High Visibility Under Bright Environments
With a brightness of 1,500 nits, 22XE1J boasts high visibility in bright environments. In addition, its clear visibility can deliver a variety of information even to those wearing polarized sunglasses.
21.5 inches of Versatile Screen Size
At 21.5 inches, this screen’s small and light size allows for flexible use in many environments. Whether utilized within a small, medium, or large business, the 22XE1J can be used in a variety of circumstances.
Secured Protection with IP56 Design
With an IP56 design that keeps the display protected from limited dust ingress and from high pressure water streams, the 22XE1J is able to operate in a variety of environments.
Wide Operating Temperature Range
22XE1J can be used within a wide range of operating temperatures and environments, which allows for outdoor installation in various climates.
Conformal Coating
Conformal Coating* improves reliability of the circuit board and power board by protecting it against dust, iron powder, and humidity.
Smart Brightness Control
The screen brightness is adjusted depending on the ambient light. The brightness is increased in light for better visibility, while it is decreased in darkness for efficient power management.
High Performance with webOS
Quad Core SoC* can execute several tasks at the same time without a separate media player. In addition, webOS 4.1 platform enhances user convenience with intuitive UI and simple app development tools.
Easy Content Distribution
& SW Update
22XE1J features embedded Wi-Fi*, Bluetooth, and Beacon which makes it easy to wirelessly distribute content and update firmware. By using Beacon and BLE (Bluetooth Low Energy), a shop manager can seamlessly display and update promotions to visitors in real time.
Real-Time & Remote Web Monitoring
With this web-based monitoring solution, users can easily control the display remotely. Users have full access to the display virtually anywhere at virtually any time from their mobile device or computer, providing them with access to current & past data, monitoring tools, and the ability to make any adjustments in real-time.
Real-time LG ConnectedCare Service
Maintenance is easy and fast with the optional LG ConnectedCare* service, a cloud service solution provided by LG. It remotely manages the status of displays in client workplaces for fault diagnosis and remote-control services, supporting the stable operation of clients’ businesses.
| Feature |
Feature Value |
| Display diagonal |
54.6 cm (21.5″) |
| Display resolution |
1920 x 1080 pixels |
| Display brightness |
1500 cd/m² |
| HD type |
Full HD |
| Touchscreen |
No |
| Panel type |
AH-IPS |
| LED backlighting type |
Edge-LED |
| Native aspect ratio |
16:9 |
| Response time |
25 ms |
| Contrast ratio (typical) |
1000:1 |
| Contrast ratio (dynamic) |
800000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Display number of colours |
16.7 million colours |
| Rated lifetime |
70000 h |
| Native refresh rate |
60 Hz |
| Haze rate |
25% |
| Surface hardness |
3H |
| RGB colour space |
NTSC |
| HDMI ports quantity |
1 |
| DVI port |
No |
| DisplayPorts quantity |
0 |
| USB port |
Yes |
| Ethernet LAN |
Yes |
| Wi-Fi |
Yes |
| USB ports quantity |
1 |
| USB version |
2.0 |
| Ethernet LAN (RJ-45) ports |
1 |
| Number of speaker outputs |
1 |
| RS-232C |
Yes |
| Product design |
Digital signage flat panel |
| Product colour |
Black |
| Placement supported |
Indoor/outdoor |
| VESA mounting |
Yes |
| Panel mounting interface |
100 x 100 mm |
| Anti-glare screen |
Yes |
| Purpose |
Universal |
| On Screen Display (OSD) |
Yes |
| Number of OSD languages |
21 |
| On Screen Display (OSD) languages |
Arabic, Simplified Chinese, Traditional Chinese, Czech, Danish, German, Dutch, English, Spanish, Finnish, French, Greek, Italian, Japanese, Korean, Norwegian, Portuguese, Russian, Swedish, Turkish |
| Operating hours (hours/days) |
24/7 |
| HDCP |
Yes |
| International Protection (IP) code |
IP56 |
| HDCP version |
1.4 |
| Power consumption (typical) |
85 W |
| Power consumption (standby) |
0.5 W |
| Power consumption (off) |
0.5 W |
| Power consumption (max) |
36 W |
| AC input voltage |
100 – 240 V |
| AC input frequency |
50 – 60 Hz |
| Computer system |
Yes |
| Built-in processor |
Yes |
| Computer system type |
System on Chip (SoC) |
| Internal memory |
16 GB |
| Operating system installed |
WebOS |
| Display width |
557.3 mm |
| Display depth |
65 mm |
| Display height |
319.8 mm |
| Display weight |
8.3 kg |
| Package width |
632 mm |
| Package depth |
187 mm |
| Package height |
394 mm |
| Package weight |
10 kg |
| Tilt angle |
15° |
| Remote control included |
Yes |
| Batteries included |
Yes |
| Power adapter included |
Yes |
| Cables included |
RS-232 |
| Tilt adjustment |
Yes |
| Operating temperature (T-T) |
-30 – 50 °C |
| Operating relative humidity (H-H) |
5 – 100% |
| Sustainability certificates |
ErP |
| Compliance certificates |
CE |
