Description
HIGH-PERFORMANCE WITH webOS 6.0
webOS 6.0, upgraded in SoC and web engine, is available on SM5J for a smooth execution of several tasks. LG webOS smart signage platform enhances user convenience with intuitive GUI and provides to SI or/and developers simple app development tools such as SDK (Software Development Kit), SCAP, sample applications.
Various Sensor Connection
LG webOS smart signage platform helps to easily provide additional solutions by supporting simple connections with external sensors* such as GPIO, NFC/RFID, temperature sensors, etc., via USB plug-in.
Mobile & Web Monitoring
Through the Control Manager, the embedded web monitoring solution, you can control and monitor the status of the SM5J series displays in different locations in real-time. It is available on internet connected devices, allowing you to flexibly and rapidly respond to emergency situations.
Compatible with AV Control System
The SM5J series supports Crestron Connected for high compatibility with professional AV controls to achieve seamless integration and automated control, boosting business management efficiency.
Real-Time LG ConnectedCare Service
Maintenance is easy and fast with the optional LG ConnectedCare service, a cloud service solution provided by LG. It remotely manages the status of displays in client workplaces for fault diagnosis and remote-control services, supporting the stable operation of clients’ businesses.
LG’s Simple Advertisement Helper, Promota
Using LG’s Promota application, downloadable on a mobile device, you can easily create your own display contents. With Promota, you can add text and images to create an online profile for your business as well as deliver information such as event news, seasonal menus, promotions, and even more while recommending easy-to-use templates relevant to your industry.
Real-Time Promotion
With Beacon and Bluetooth Low Energy (BLE), shop managers can provide coupons and information in real-time.
Content Sharing
Content Mirroring among devices is available on a Wi-Fi network.
Wireless Access Point
The SM5J series operates as a virtual router which can be an wireless access point for mobile devices.
| Feature |
Feature Value |
| Display diagonal |
81.3 cm (32″) |
| Display technology |
IPS |
| Display resolution |
1920 x 1080 pixels |
| Display brightness |
400 cd/m² |
| HD type |
Full HD |
| Response time |
10 ms |
| Contrast ratio (typical) |
1100:1 |
| Contrast ratio (dynamic) |
1000000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Haze rate |
1% |
| HDMI ports quantity |
3 |
| USB port |
Yes |
| Ethernet LAN |
Yes |
| Wi-Fi |
Yes |
| HDMI version |
2.2 |
| USB ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
1 |
| Audio (L/R) in |
1 |
| Audio (L/R) out |
1 |
| RS-232C |
Yes |
| Built-in speaker(s) |
Yes |
| Number of built-in speakers |
2 |
| RMS rated power |
10 W |
| Product design |
Digital signage flat panel |
| Product colour |
Black |
| VESA mounting |
Yes |
| Orientation |
Horizontal/Vertical |
| Panel mounting interface |
200 x 200 mm |
| Operating hours (hours/days) |
24/7 |
| Power consumption (typical) |
55 W |
| Energy efficiency class (SDR) |
A |
| AC input voltage |
100 – 240 V |
| AC input frequency |
50 – 60 Hz |
| Heat dissipation |
187.67 BTU/h |
| Internal memory |
8 GB |
| Operating system installed |
WebOS |
| Base width |
1.3 cm |
| Width |
729.4 mm |
| Depth |
55.5 mm |
| Height |
428.9 mm |
| Weight |
5.7 kg |
| Width (with stand) |
729.4 mm |
| Depth (with stand) |
154.2 mm |
| Height (with stand) |
481 mm |
| Weight (with stand) |
6.5 kg |
| Remote control included |
Yes |
| Cables included |
AC, HDMI, RS-232 |
| Mounting kit |
Yes |
| Operating temperature (T-T) |
0 – 40 °C |
| Operating relative humidity (H-H) |
10 – 80% |
| Country of origin |
South Korea |
| Harmonized System (HS) code |
85285210 |
| Heat dissipation (max) |
255.911 BTU/h |
| Sustainability certificates |
ErP |
