Description
Incredible Immersion with
Ultra-Narrow Bezel
Seamless Large Screens with Ultra-Narrow Bezel
The ultra-narrow bezel creates a visually stunning digital wall to effectively deliver dynamic content and immerse the viewers. The large screen it generates is enough to captivate the attention of passersby.
Image Gap Reduction
The VL5G series includes an image improvement algorithm that can reduce image gaps among tiled displays when playing back videos. Objects located on the bezel boundaries are adjusted for a seamless viewing experience.
Higher Viewing Angle
Large screens are usually positioned higher than human-eye level, making uniform picture quality essential for video walls. The viewing angle of the VL5G series is high enough to display vivid colors throughout the screen with no distortion
Wide Viewing Angle
It is well known that LG IPS panel technology enables better control of liquid crystals, which in turn allows the screen to be viewed from virtually any angle. Because of this, the VL5G series captures the attention of and captivates more viewers with lifelike colors, regardless of their viewing position.
Easy Color Adjustment
Depending on the content, the color temperature of the display can be easily adjusted in increments of 100K using a remote control.
White Balance Adjustment
In conventional video walls, white balance was adjustable only in “full-white” mode, but the VL5G series allows you to modify each value of grey scale to achieve more detailed and precise white balance adjustment.
User-Friendly Menu Structure
The menu structure has been optimized for commercial use. It simplifies approach flows and groups similar functions together, adopting a more intuitive GUI for ease of use. This way, users can avoid having to do trial-and-error when exploring desired functions and managing displays.
Intuitive GUI
The GUI (Graphic User Interface) is carefully designed with a four-way navigation remote control that lets users easily switch to other settings. Also, it adopts a large font for better visibility, which is necessary when users want to control displays from relatively far distances.
| Feature |
Feature Value |
| Display diagonal |
124.5 cm (49″) |
| Display resolution |
1920 x 1080 pixels |
| Display brightness |
500 cd/m² |
| HD type |
Full HD |
| Panel type |
IPS |
| LED backlighting type |
Direct-LED |
| Native aspect ratio |
16:9 |
| Response time |
8 ms |
| Contrast ratio (typical) |
1000:1 |
| Contrast ratio (dynamic) |
500000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Display number of colours |
1.07 billion colours |
| Panel life |
50000 h |
| Rated lifetime |
60000 h |
| Native refresh rate |
60 Hz |
| Haze rate |
3% |
| HDMI ports quantity |
2 |
| DVI port |
Y |
| DisplayPorts quantity |
2 |
| USB port |
Y |
| Ethernet LAN |
Y |
| HDMI version |
1.4 |
| HDMI input ports quantity |
2 |
| DVI-D ports quantity |
1 |
| DisplayPorts in |
1 |
| DisplayPorts out |
1 |
| USB ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
1 |
| Audio (L/R) in |
1 |
| Audio (L/R) out |
1 |
| RS-232 interface |
Y |
| RS-232C |
Y |
| Remote (IR) input |
1 |
| Product design |
Digital signage flat panel |
| Product colour |
Black |
| Placement supported |
Indoor |
| VESA mounting |
Y |
| Orientation |
Horizontal/Vertical |
| Panel mounting interface |
600 x 400 mm |
| Bezel width (bottom) |
1.25 mm |
| Bezel width (side) |
1.25 mm |
| Bezel width (top) |
2.25 mm |
| Mounting type |
Wall |
| Purpose |
Commercial |
| On Screen Display (OSD) |
Y |
| Number of OSD languages |
20 |
| On Screen Display (OSD) languages |
Arabic, Simplified Chinese, Traditional Chinese, Czech, Danish, German, Dutch, English, Spanish, Finnish, French, Greek, Italian, Japanese, Korean, Norwegian, Portuguese, Russian, Swedish |
| Operating hours (hours/days) |
24/7 |
| Power consumption (typical) |
100 W |
| Power consumption (off) |
0.5 W |
| Energy efficiency class (SDR) |
G |
| Energy consumption (SDR) per 1000 hours |
80 kWh |
| AC input voltage |
100 – 240 V |
| AC input frequency |
50 – 60 Hz |
| Heat dissipation |
341 BTU/h |
| Energy efficiency scale |
A to G |
| Display width |
1077.6 mm |
| Display depth |
89.7 mm |
| Display height |
607.8 mm |
| Display weight |
16.9 kg |
| Package width |
1214 mm |
| Package depth |
263 mm |
| Package height |
778 mm |
| Package weight |
29.3 kg |
| Remote control included |
Y |
| Batteries included |
Y |
| Cables included |
AC, RS-232 |
| Operating temperature (T-T) |
0 – 40 °C |
| Operating relative humidity (H-H) |
10 – 80% |
| Harmonized System (HS) code |
85285210 |
| Heat dissipation (max) |
409 BTU/h |
