Description
See Beyond, LG Transparent OLED Touch Signage
A New Level of See-through View
LG Transparent OLED Signage illuminates spaces that once were hidden away behind the display, completely harmonizing with its surroundings.
Boasting vivid and clear colors with high transparency, this display provides visual enhancements to objects placed behind it, giving viewers an impressive “wow” factor.
Not only that, it can respond according to viewers’ touch, which has great potential for various applications where customer interactions are required.
Accurate and Vivid Colors
Featuring self-lighting pixels, the display maintains vivid colors and high contrast ratio even when the display becomes transparent. It brings content to life from wide viewing angles, and the content blends into its surroundings seamlessly and naturally.
Intuitive P-Cap Touch
By adding P-Cap touch sensor film to the display, the utilization possibilities expand to various industries where customer interaction services are demanding. Users could enjoy its fascinating content using their fingertips with no lag.
High Transparency
LG’s OLED technology makes the Transparent OLED Touch Signage have slimmer structure without backlight unit nor a liquid crystal layer, achieving high transparency of 33% even with P-Cap touch film. While clearly showing objects behind the screen, it overlays the relevant information right before them.
Protective Tempered Glass
Touching a display directly can cause damage or scratches. The tempered front glass protects product from such external impacts and its anti-shatter glass is designed to minimize customers’ injuries.
Expandable Design
LG Transparent OLED Touch Signage is designed as a semi-assembled display, meaning you can install it in various ways to fit into existing structures and spaces. With a variety of forms of installation*, it can complement any venue in which it is installed.
| Feature |
Feature Value |
| Display diagonal |
139.7 cm (55″) |
| Display technology |
OLED |
| Display resolution |
1920 x 1080 pixels |
| Display brightness |
400 cd/m² |
| HD type |
Full HD |
| Touchscreen |
Yes |
| LED backlight |
Yes |
| Number of simultaneous touchpoints |
10 |
| Multi-touch |
Yes |
| Native aspect ratio |
16:9 |
| Response time |
8 ms |
| Contrast ratio (typical) |
150000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Display number of colours |
1.07 billion colours |
| Display diagonal (metric) |
138.8 cm |
| Panel life |
30000 h |
| Transparency |
33% |
| Native refresh rate |
120 Hz |
| Haze rate |
3% |
| Touch response time |
120 ms |
| Glass thickness |
3 mm |
| HDMI ports quantity |
1 |
| DVI port |
No |
| DisplayPorts quantity |
2 |
| USB port |
Yes |
| Ethernet LAN |
Yes |
| Wi-Fi |
No |
| HDMI version |
1.4 |
| HDMI input ports quantity |
1 |
| DisplayPorts in |
1 |
| DisplayPorts out |
1 |
| DisplayPort version |
1.3 |
| USB ports quantity |
3 |
| USB version |
2.0 |
| USB connector type |
USB Type-A, USB Type-B |
| USB 2.0 Type-B ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
2 |
| RS-232C |
Yes |
| Remote (IR) input |
1 |
| Remote (IR) output |
1 |
| Built-in speaker(s) |
No |
| Product design |
Digital signage flat panel |
| Product colour |
Silver |
| Orientation |
Horizontal/Vertical |
| Screen shape |
Flat |
| Bezel type |
4 Bezel-less |
| Bezel width (bottom) |
14.4 cm |
| Bezel width (side) |
7.9 mm |
| Bezel width (top) |
7.9 mm |
| Anti-glare screen |
Yes |
| Positioning accuracy |
3.5 mm |
| Purpose |
Commercial |
| Number of OSD languages |
20 |
| On Screen Display (OSD) languages |
Arabic, Simplified Chinese, Traditional Chinese, Czech, Danish, German, Dutch, English, Spanish, Finnish, French, Greek, Italian, Japanese, Korean, Norwegian, Portuguese, Russian, Swedish |
| Operating hours (hours/days) |
18/7 |
| Power consumption (typical) |
280 W |
| Power consumption (standby) |
2 W |
| Power consumption (off) |
0.5 W |
| Power consumption (max) |
300 W |
| Energy consumption (SDR) per 1000 hours |
85 kWh |
| AC input voltage |
100-240 V |
| AC input frequency |
50/60 Hz |
| Heat dissipation |
1023 BTU/h |
| Computer system |
No |
| Built-in processor |
No |
| Internal memory |
16 GB |
| Operating system installed |
WebOS |
| Operating system version |
4.0 |
| Display width |
1225.5 mm |
| Display depth |
7.4 mm |
| Display height |
832.9 mm |
| Display weight |
12.9 kg |
| Base width |
78.3 cm |
| Base depth |
3.47 cm |
| Base height |
23.8 cm |
| Base weight |
3.4 kg |
| Package width |
1345 mm |
| Package depth |
207 mm |
| Package height |
945 mm |
| Package weight |
24.5 kg |
| Remote control included |
Yes |
| Batteries included |
Yes |
| Cables included |
HDMI, Power, RS-232 |
| Mounting kit |
Yes |
| Operating temperature (T-T) |
0 – 40 °C |
| Operating relative humidity (H-H) |
10 – 80% |
| Certification |
CB / NRTL
FCC Class “A” / CE / KC |
