Description
All-in-One
LED Screen with Built-in Speaker
The LAEC series is a 136-inch large screen which is offered as an all-in-one package including an embedded controller and built-in speaker. Eliminating the prejudice that LED displays are difficult and complex to install, it doesn’t require controller connections or module configuration. After a simple installation process, all you need to do is to turn on the screen with a remote control like home TV.
Quick Maintenance
In case of failure related to the LED module or the system board, it can be serviced from the front. The LED module can be simply detached by the provided magnetic tool and replaced quickly without cabling.
LG’s Wireless Screen Sharing Solution, LG One:Quick Share
LG One:Quick Share is a wireless screen sharing solution available through the LAEC series, USB transmission unit, and its app. You can simply share personal PC screen to the display with it’s USB dongle button and embedded Wi-Fi, and can adjust the basic setting values (volume, picture mode, auto bright, etc.) of the connected display without a remote control. Also, the Office Meeting Mode helps you to display the agenda, note before the meeting starts.
Easy Installation
The installation process of the All-in-One Smart series is very simple. After securing two cabinets which are included in the flight kit, attach each LED display module to them. Lastly, plug in the power cable. This simple installation saves time and labor, thereby making users handle the LED screen with ease.
Dedicated Installation Accessories
The product is offered with the flight case which includes every necessary component including the landscape wall mount and tools for installation. The motorized stand is provided as an option, so that you can easily place it depending on your installation sites. With this stand, you can adjust a height of the screen including stand from 2.0 m to 2.5 m.
Compatible with AV Control Systems
The LAEC series supports Crestron Connected® for high compatibility with professional AV controls to achieve seamless integration and automated control, boosting business management efficiency.
Simple Power Connection
The LAEC series is operated with a single or double AC cable without the need for a complicated power connection and enables neat installation.
Real-Time LG ConnectedCare
Maintenance is easy and fast with the optional LG ConnectedCare service, a cloud service solution provided by LG. It remotely manages the status of displays in client workplaces for fault diagnosis and remote-control services, enabling the stable operation of clients businesses.
| Feature |
Feature Value |
| Display diagonal |
3.45 m (136″) |
| Display technology |
LED |
| Display resolution |
1920 x 1080 pixels |
| Display brightness |
500 cd/m² |
| HD type |
Full HD |
| Touchscreen |
No |
| Contrast ratio (typical) |
3000:1 |
| Viewing angle, horizontal |
160° |
| Viewing angle, vertical |
160° |
| HDMI ports quantity |
0 |
| DVI port |
No |
| DisplayPorts quantity |
0 |
| USB port |
Yes |
| Ethernet LAN |
No |
| Wi-Fi |
Yes |
| Built-in speaker(s) |
Yes |
| Number of built-in speakers |
2 |
| RMS rated power |
9 W |
| Product design |
Digital signage flat panel |
| Product colour |
Black |
| Placement supported |
Indoor |
| Orientation |
Horizontal |
| Mounting type |
Wall |
| Purpose |
Universal |
| Power consumption (typical) |
800 W |
| Power consumption (max) |
2000 W |
| AC input voltage |
100 – 240 V |
| AC input frequency |
50 – 60 Hz |
| Computer system |
No |
| Built-in processor |
No |
| Width |
3004.6 mm |
| Depth |
36.5 mm |
| Height |
1692.1 mm |
| Weight |
129 kg |
| Operating temperature (T-T) |
0 – 40 °C |
| Certification |
FCC,ETL,CB |
| Harmonized System (HS) code |
85285210 |
| Compliance certificates |
CE, REACH, RoHS |
