Description
Class-leading performance and value
For best-in-class visual performance and value, the second generation ME series commands feature-rich professional capabilities for meeting rooms and signage applications. The multi-functional Sharp MultiSync® displays with high haze panel, native USB-C connectivity, and quick input detection appeals to Enterprise users for Bring Your Own Device simplicity, supporting hybrid workflows and spontaneous meetings.
An integrated System on Chip (SoC) with Android 13 CTS-compliant Operating System brings the most up to date features and security, powering signage applications and commanding high compatibility with CMS partners, making the multi-purpose Sharp MultiSync® ME series suitable for cost sensitive retail signage applications. Experience seamless access to Android apps and install apps directly on the display using the integrated browser, without the hassle and expense of an additional external media player.
Trusted long-life reliability is assured through Japanese engineering standards and high-quality components. The Sharp MultiSync® ME series is a class-leading solution for today’s workplace challenges, bringing value and professional performance, without compromise.
| Feature |
Feature Value |
| Display diagonal |
139.7 cm (55″) |
| Display technology |
LCD |
| Display resolution |
3840 x 2160 pixels |
| Display brightness |
450 cd/m² |
| HD type |
4K Ultra HD |
| Touchscreen |
No |
| Panel type |
IPS |
| LED backlight |
Yes |
| LED backlighting type |
Direct-LED |
| Native aspect ratio |
16:9 |
| Response time |
8 ms |
| Contrast ratio (typical) |
1200:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Display number of colours |
1.073 billion colours |
| Display diagonal (metric) |
138.8 cm |
| Horizontal scan range |
15 – 135 kHz |
| Vertical scan range |
23 – 76 Hz |
| Native refresh rate |
60 Hz |
| Haze rate |
25% |
| HDMI ports quantity |
7 |
| DVI port |
No |
| USB port |
Yes |
| Ethernet LAN |
Yes |
| HDMI input ports quantity |
6 |
| HDMI output ports quantity |
1 |
| USB ports quantity |
5 |
| USB 2.0 Type-B ports quantity |
3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
2 |
| Ethernet LAN (RJ-45) ports |
1 |
| Ethernet LAN data rates |
100 Mbit/s |
| RS-232 interface |
Yes |
| Built-in speaker(s) |
Yes |
| Number of built-in speakers |
2 |
| RMS rated power |
20 W |
| Product design |
Digital signage flat panel |
| Product colour |
Black |
| VESA mounting |
Yes |
| Orientation |
Horizontal/Vertical |
| Screen shape |
Flat |
| Panel mounting interface |
400 x 400 mm |
| Purpose |
Universal |
| Operating hours (hours/days) |
18/7 |
| HDCP |
Yes |
| Energy efficiency class (SDR) |
G |
| Energy efficiency class (HDR) |
G |
| Energy consumption (SDR) per 1000 hours |
123 kWh |
| Energy consumption (HDR) per 1000 hours |
124 kWh |
| AC input voltage |
100 – 240 V |
| AC input frequency |
50 – 60 Hz |
| Energy efficiency scale |
A to G |
| Internal memory |
4 GB |
| Internal storage capacity |
32 GB |
| Operating system installed |
Android |
| Operating system version |
Android 13 |
| Video formats supported |
H.264, HEVC/H.265, MP4, MPEG1, MPEG2 |
| Audio formats supported |
MP3 |
| Display width |
1233 mm |
| Display depth |
62 mm |
| Display height |
703.5 mm |
| Display weight |
13.2 kg |
| Package width |
1332 mm |
| Package depth |
156 mm |
| Package height |
819 mm |
| Package weight |
20.3 kg |
| Batteries included |
Yes |
| Cables included |
HDMI, Power |
| Operating temperature (T-T) |
0 – 40 °C |
| Operating relative humidity (H-H) |
20 – 80% |
| Storage temperature (T-T) |
-20 – 60 °C |
| Storage relative humidity (H-H) |
10 – 90% |
