Description
Features
Power Distribution
– Space saving 1U rack mount design with rear mounting
– IEC or NEMA outlet models
– 3 digit 7-segment front panel LED shows Current / IP Address
– Remote users can monitor outlet status via web pages on their browsers
– Safe shutdown support
– Separate power for the unit’s own power and its power outlets. The user interface is still accessible even when an overload condition trips the devices’ circuit breaker
Remote Access
– Remote power control via TCP/IP and a built in 10/100 Ethernet port
– Network Interfaces: TCP/IP, UDP, HTTP, HTTPS, SSL, SMTP, DHCP, NTP, DNS, 10Base-T/100Base-TX, auto sense, Ping
– eco PDU Power Management software – eco Sensors
– Supports SNMP Manager V3
Operation
– Local and Remote power outlet control (On, Off, Power Cycle) by individual outlets
– Power-on sequencing – users can set the power on sequence and delay time for each port to allow equipment to be turned on in the proper order
– Easy setup and operation via a browser-based user interface
– Multibrowser support (IE, Firefox, Chrome, Safari)
– RTC support to keep the timer running during times of no power.
– Supports up to 8 user and 1 administrator accounts
Management
– Power status measurement at the PDU or Outlet level
– LED indicators for current and IP address at Outlet levels
– Real-time current, voltage, and kWH displayed in a browsed-based UI for monitoring at the outlet level (PE8108 / PE8208)
– Current and voltage threshold setting
– Naming support for outlets
– User outlet access assignment on an outlet-by-outlet basis.
– Event logging and syslog support
– Upgradeable firmware
– Multilanguage support: English, German, Traditional Chinese, Simplified Chinese, Japanese, French, Spanish, Italian
Security
– Two-level password security
– Strong security features include password protection and advanced encryption technologies – 128 bit SSL
– Remote authentication support: RADIUS
eco Sensors Energy Management Software
– Automatic discovery of all PE devices within the same intranet
– Remote real-time power measurement and monitoring
– Remote real-time power outlet management
– Remote real-time environment sensor monitoring
– Plotting/Monitoring of all PE devices
– Exceed threshold alert through SMTP and Syslog
– Power Analysis Report
Package Contents
– 1x PE8108 Power Distribution Unit
– 1x Power Cord
– 1x Rack Mount Kit
– 1x Software CD
– 1x User Instructions
| Feature |
Feature Value |
| PDU types |
Monitored |
| Rack capacity |
1U |
| Mounting |
Horizontal |
| Housing material |
Metal |
| Product colour |
Black |
| AC outlets quantity |
8 AC outlet(s) |
| AC outlet types |
C13 coupler |
| Power plug |
C20 coupler |
| Ethernet LAN (RJ-45) ports |
1 |
| LED indicators |
LAN, Link, Power, Status |
| Monitoring |
Current |
| Nominal input voltage |
100-240 V |
| Maximum current |
10 A |
| AC input frequency |
50 – 60 Hz |
| Nominal output voltage |
100-240 V |
| Maximum input current per phase |
10 A |
| Dimensions (WxDxH) |
219.3 x 432.4 x 44 mm |
| Weight |
2.87 kg |
| Operating temperature (T-T) |
0 – 50 °C |
| Storage temperature (T-T) |
-20 – 60 °C |
| Operating relative humidity (H-H) |
0 – 80% |
| Sustainability certificates |
RoHS |
