Riello Sentinel Rack 1500 uninterruptible power supply (UPS) Double-conversion (

Part No:
SER-1500
Full Product Specs
Price Locked for 30 Days:
Lock Added: N/A
exc VAT
£774.88
£929.85
inc VAT
Save 5% - First order discount - Any product - Any price*
Use Promo Code: FIRST5
*This promotion may only be used once, 5% discount is applied to your first order. Can not be used in-conjunction with any other offers. Not available if paying with PayPal.
Last few available! Order now: Only 2 left.

SENTINEL RACK 1.5KVA

2 in stock (can be backordered)

Non-Returnable*

Safe & Secure shopping

*This item is non-returnable and non-cancellable due to customisation or built to order.

SKU: SER-1500 Category:

Can't find what your looking for?

Our qualified I.T. experts are here & ready to help.

Contact us on 0203 617 7663 or email us directly
Riello

Related products

Description

Compactness and total protection for rack systems.

The Sentinel Rack is a rack-mounted version of the popular Sentinel Pro range of ON LINE uninterruptible power supplies. Advanced double conversion technology provides the highest levels of reliability and protection for critical servers, data processing IT systems, and voice/data applications. Available in 1500 VA and 3000 VA versions, both products sit at just 380mm deep, making them the ideal choice to upgrade power in server rooms housing 600 mm deep legacy racks.

For applications requiring several hours of autonomy, the SER 3000 ER is fitted with a 6 A battery charger and additional battery packs for extra runtime. These plug and play UPS systems are designed to fit standard 19″ inch cabinet racks and incorporate a Cold Start feature that enables them to power up even if there isn’t a mains supply. Choose from a wide range of operating modes (i.e. ON LINE, ECO, SMART ACTIVE, STANDBY OFF, Frequency Converter) to boost performance and improve energy efficiency.

Feature Feature Value
UPS topology Double-conversion (Online)
Output power capacity 1.5 kVA
Output power 1350 W
Waveform Sine/Square
Input operation voltage (min) 220 V
Input operation voltage (max) 240 V
Input frequency 50/60 Hz
Output operation voltage (min) 180 V
Output operation voltage (max) 264 V
Output frequency 50/60 Hz
Output voltage regulation 5%
Surge energy rating 300 J
Response time 100 ms
Number of input phases 1
Number of output phases 1
Efficiency 98%
Power factor 0.99
Crest factor 3:1
ECO mode Yes
Noise level 40 dB
Surge protection Yes
Power protection features Battery discharge, Over current, Over voltage, Overheating, Short circuit, Under voltage
Auto-restart Yes
Power source type AC
AC outlet types C13 coupler, IEC 320
AC outlets quantity 1 AC outlet(s)
Number of output IEC jumpers 8
USB port Yes
RS-232 ports 1
Battery technology Sealed Lead Acid (VRLA)
Battery recharge time 4 h
Form factor Rackmount
Product colour Black
Rack capacity 1U
Cooling type Active
Built-in fan Yes
Control type Buttons
Display type LED
Certification CE, L V 2014/35/EU, EMC 2014/30/EU, IEC EN 62040-1; EMC IEC EN 62040-2, IEC 62040-3 VFI – SS – 111
Operating temperature (T-T) 0 – 40 °C
Operating relative humidity (H-H) 5 – 95%
Sustainability certificates CE, RoHS
Width 450 mm
Depth 380 mm
Height 87 mm
Weight 22 kg

Additional information

UPS topology

Double-conversion (Online)
Output power

1350 W
Input frequency

50/60 Hz
Output voltage regulation

5%
Response time

100 ms
Number of output phases

1
Power factor

0.99
ECO mode

Yes
Surge protection

Yes
Auto-restart

Yes
AC outlet types

C13 coupler, IEC 320
RS-232 ports

1
Battery recharge time

4 h
Product colour

Black
Cooling type

Active
Control type

Buttons
Certification

CE, L V 2014/35/EU, EMC 2014/30/EU, IEC EN 62040-1; EMC IEC EN 62040-2, IEC 62040-3 VFI – SS – 111
Width

450 mm
Height

87 mm
Output power capacity

1.5 kVA
Waveform

Sine/Square
Output frequency

50/60 Hz
Surge energy rating

300 J
Number of input phases

1
Efficiency

98%
Crest factor

3:1
Noise level

40 dB
Power protection features

Battery discharge, Over current, Over voltage, Overheating, Short circuit, Under voltage
Power source type

AC
AC outlets quantity

1 AC outlet(s)
USB port

Yes
Battery technology

Sealed Lead Acid (VRLA)
Form factor

Rackmount
Rack capacity

1U
Built-in fan

Yes
Display type

LED
Operating temperature (T-T)

0 – 40 °C
Sustainability certificates

CE, RoHS
Depth

380 mm
Weight

22 kg
