Description
Intel NUC NUC10i5FNHN UCFF Black i5-10210U 1.6 GHz UK Price
Intel® Optane™ Memory Supported
Intel® Optane™ memory is a revolutionary new class of non-volatile memory that sits in between system memory and storage to accelerate system performance and responsiveness. When combined with the Intel® Rapid Storage Technology Driver, it seamlessly manages multiple tiers of storage while presenting one virtual drive to the OS, ensuring that data frequently used resides on the fastest tier of storage. Intel® Optane™ memory requires specific hardware and software configuration. Visit www.intel.com/OptaneMemory for configuration requirements.
Intel® Virtualization Technology for Directed I/O (VT-d)
Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.
Intel® Rapid Storage Technology
Intel® Rapid Storage Technology provides protection, performance, and expandability for desktop and mobile platforms. Whether using one or multiple hard drives, users can take advantage of enhanced performance and lower power consumption. When using more than one drive the user can have additional protection against data loss in the event of hard drive failure. Successor to Intel® Matrix Storage Technology.
Intel® Virtualization Technology (VT-x)
Intel® Virtualization Technology (VT-x) allows one hardware platform to function as multiple “virtual” platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.
Intel® Platform Trust Technology (Intel® PTT)
Intel® Platform Trust Technology (Intel® PTT) is a platform functionality for credential storage and key management used by Windows 8* and Windows® 10. Intel® PTT supports BitLocker* for hard drive encryption and supports all Microsoft requirements for firmware Trusted Platform Module (fTPM) 2.0.
FeatureFeature Value
| Built-in processor |
Y |
| Processor manufacturer |
Intel |
| Processor family |
Intel® Core™ i5 |
| Processor generation |
10th gen Intel® Core™ i5 |
| Processor model |
i5-10210U |
| Processor frequency |
1.6 GHz |
| Processor cores |
4 |
| Processor threads |
8 |
| Processor lithography |
14 nm |
| Processor boost frequency |
4.2 GHz |
| Processor cache |
6 MB |
| Thermal Design Power (TDP) |
25 W |
| Memory bandwidth supported by processor (max) |
42.6 GB/s |
| CPU configuration (max) |
1 |
| Memory slots type |
SO-DIMM |
| Number of memory slots |
2 |
| Number of DIMM slots |
2 |
| Maximum internal memory |
64 GB |
| Supported memory clock speeds |
2666 MHz |
| Supported memory types |
DDR4-SDRAM |
| Memory channels |
Dual-channel |
| Memory bandwidth (max) |
42.6 GB/s |
| Memory voltage |
1.2 V |
| Removable memory card slot |
SDXC with UHS-II support |
| ECC |
N |
| Non-ECC |
Y |
| Supported storage drive types |
HDD & SSD |
| Storage drive sizes supported |
M.2,2.5 |
| SSD form factor |
M.2 |
| Storage drive interface |
M.2, Serial ATA III |
| Number of storage drives supported |
2 |
| RAID levels |
0, 1 |
| Card reader integrated |
Y |
| Compatible memory cards |
SD, SDHC, SDXC |
| On-board graphics card |
N |
| On-board graphics card model |
Intel® UHD Graphics |
| Discrete graphics card model |
Not available |
| Number of displays supported |
3 |
| Built-in speaker(s) |
N |
| Ethernet LAN |
Y |
| Wi-Fi |
Y |
| Top Wi-Fi standard |
Wi-Fi 6 (802.11ax) |
| Wi-Fi standards |
Wi-Fi 6 (802.11ax) |
| WLAN controller model |
Intel Wi-Fi 6 AX201 |
| LAN controller |
Intel® I219-V |
| Bluetooth |
Y |
| Bluetooth version |
5.2 |
| HDMI ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
3 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
2 |
| Internal USB 2.0 ports quantity |
2 |
| HDMI version |
2.0b |
| Combo headphone/mic port |
Y |
| Number of SATA III connectors |
2 |
| USB version |
2.0/3.2 Gen 2 (3.1 Gen 2) |
| USB ports quantity |
7 |
| Thunderbolt 3 ports quantity |
1 |
| M.2 card slot (storage) |
2242/2280 |
| DC-in jack |
Y |
| PCI Express slots version |
3.0 |
| Chassis type |
UCFF |
| Product colour |
Black |
| Cooling type |
Active |
| Product type |
Mini PC barebone |
| On/off switch |
Y |
| ARK ID |
214591 |
| Motherboard form factor |
UCFF |
| Trusted Platform Module (TPM) |
N |
| Audio output channels |
7.1 channels |
| Consumer infrared Rx sensor |
Y |
| Windows operating systems supported |
Windows 10 x64 |
| Compatible operating systems |
Windows 11 (64-bit), Windows 10 (64-bit) |
| Commodity Classification Automated Tracking System (CCATS) |
G157815L2 |
| Export Control Classification Number (ECCN) |
5A992C |
| Intel® vPro™ Platform Eligibility |
N |
| Intel® High Definition Audio (Intel® HD Audio) |
N |
| Embedded options available |
N |
| Intel Rapid Storage Technology |
Y |
| Intel® AES New Instructions (Intel® AES-NI) |
Y |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Y |
| Intel VT-x with Extended Page Tables (EPT) |
Y |
| Intel 64 |
Y |
| Idle States |
Y |
| Enhanced Intel SpeedStep Technology |
Y |
| Intel Flex Memory Access |
Y |
| Intel Trusted Execution Technology |
N |
| Execute Disable Bit |
Y |
| Intel TSX-NI |
N |
| Intel Stable Image Platform Program (SIPP) |
N |
| Intel Clear Video Technology |
Y |
| Intel® Optane™ Memory Ready |
Y |
| Intel® Platform Trust Technology (Intel® PTT) |
Y |
| Intel Virtualization Technology (VT-x) |
Y |
| Harmonized System (HS) code |
84713000 |
| Power supply type |
External AC adapter |
| Width |
117 mm |
| Depth |
112 mm |
| Height |
51 mm |
| Power cord included |
N |
| Additional headers |
CEC, 2x USB2.0, FRONT_PANEL, RGB |
| Number of SATA connectors |
2 |
| HDD size |
2.5″ |
| DC input voltage |
19 V |
| Status |
Launched |
| Launch date |
Q2’21 |
