| Processor family |
IntelĀ® Coreā¢ i5 |
| Processor manufacturer |
Intel |
| Processor model |
i5-10500 |
| Processor frequency |
3.1 GHz |
| Processor generation |
10th gen IntelĀ® Coreā¢ i5 |
| Processor cores |
6 |
| Processor boost frequency |
4.5 GHz |
| Processor socket |
LGA 1200 (Socket H5) |
| Processor cache |
12 MB |
| Processor cache type |
L3 |
| Processor threads |
12 |
| System bus rate |
8 GT/s |
| Processor lithography |
14 nm |
| Processor operating modes |
64-bit |
| Processor codename |
Comet Lake |
| Thermal Design Power (TDP) |
65 W |
| Tjunction |
100 Ā°C |
| PCI Express slots version |
3.0 |
| Maximum number of PCI Express lanes |
16 |
| PCI Express configurations |
1×16, 2×8, 1×8+2×4 |
| Maximum internal memory supported by processor |
128 GB |
| Memory types supported by processor |
DDR4-SDRAM |
| Memory clock speeds supported by processor |
2666 MHz |
| Memory bandwidth supported by processor (max) |
41.6 GB/s |
| Internal memory |
16 GB |
| Maximum internal memory |
128 GB |
| Internal memory type |
DDR4-SDRAM |
| Memory layout (slots x size) |
1 x 16 GB |
| Memory slots |
4x DIMM |
| Memory clock speed |
2666 MHz |
| ECC |
No |
| Total storage capacity |
256 GB |
| Optical drive type |
No |
| Storage media |
SSD |
| Card reader integrated |
No |
| Total SSDs capacity |
256 GB |
| Number of SSDs installed |
1 |
| SSD capacity |
256 GB |
| SSD interface |
PCI Express, NVMe |
| NVMe |
Yes |
| SSD form factor |
M.2 |
| Discrete graphics card |
No |
| On-board graphics card |
Yes |
| Discrete graphics card model |
Not available |
| On-board graphics card model |
IntelĀ® UHD Graphics 630 |
| On-board graphics card base frequency |
350 MHz |
| On-board graphics card dynamic frequency (max) |
1150 MHz |
| Maximum on-board graphics card memory |
64 GB |
| Number of displays supported (on-board graphics) |
3 |
| On-board graphics card DirectX version |
12.0 |
| On-board graphics card OpenGL version |
4.5 |
| On-board graphics card ID |
0x9BC8 |
| Ethernet LAN |
Yes |
| Wi-Fi |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Cabling technology |
10/100/1000Base-T(X) |
| Top Wi-Fi standard |
Wi-Fi 6 (802.11ax) |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| WLAN controller manufacturer |
Intel |
| WLAN controller model |
Intel Wi-Fi 6 AX201 |
| Antenna type |
2×2 |
| Bluetooth |
Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
6 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
1 |
| HDMI ports quantity |
1 |
| DVI port |
No |
| HDMI version |
2.0 |
| DisplayPorts quantity |
2 |
| DisplayPort version |
1.4 |
| Ethernet LAN (RJ-45) ports |
1 |
| Microphone in |
No |
| Headphone outputs |
1 |
| Line-out |
Yes |
| Combo headphone/mic port |
Yes |
| PCI Express x1 (Gen 3.x) slots |
2 |
| PCI Express x16 (Gen 3.x) slots |
2 |
| Chassis type |
SFF |
| Product colour |
Black |
| Product type |
PC |
| Market positioning |
Business |
| Motherboard chipset |
Intel Q470 |
| Operating system installed |
Windows 10 Pro |
| Operating system architecture |
64-bit |
| Intel 64 |
Yes |
| Enhanced Intel SpeedStep Technology |
Yes |
| Embedded options available |
No |
| IntelĀ® InTruā¢ 3D Technology |
Yes |
| IntelĀ® Clear Video HD Technology (IntelĀ® CVT HD) |
Yes |
| Intel Clear Video Technology |
Yes |
| Intel VT-x with Extended Page Tables (EPT) |
Yes |
| Idle States |
Yes |
| Thermal Monitoring Technologies |
Yes |
| Intel Stable Image Platform Program (SIPP) |
Yes |
| IntelĀ® AES New Instructions (IntelĀ® AES-NI) |
Yes |
| IntelĀ® Secure Key |
Yes |
| IntelĀ® OS Guard |
Yes |
| Intel Trusted Execution Technology |
Yes |
| Execute Disable Bit |
Yes |
| Intel Software Guard Extensions (Intel SGX) |
Yes |
| Processor package size |
37.5 x 37.5 mm |
| Supported instruction sets |
SSE4.1, SSE4.2, AVX 2.0 |
| Scalability |
1S |
| CPU configuration (max) |
1 |
| Thermal solution specification |
PCG 2015C |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
| Intel Virtualization Technology (VT-x) |
Yes |
| Processor ARK ID |
199277 |
| IntelĀ® Turbo Boost Technology |
2.0 |
| IntelĀ® Hyper Threading Technology (IntelĀ® HT Technology) |
Yes |
| IntelĀ® Quick Sync Video Technology |
Yes |
| IntelĀ® Identity Protection Technology (IntelĀ® IPT) |
Yes |
| HP JumpStart |
Yes |
| HP Support Assistant |
Yes |
| HP Management tools |
HP BIOS Config Utility (download); HP Client Catalog (download); HP Driver Packs (download); HP Cloud Recovery; HP Management Integration Kit for Microsoft System Center Configuration Management Gen 4; HP Image Assistant Gen 5 |
| HP segment |
Business |
| Power supply |
350 W |
| Low halogen |
Yes |
| Sustainability certificates |
ENERGY STAR |
| Sustainable technologies and materials |
Low halogen |
| Width |
338 mm |
| Depth |
308 mm |
| Height |
100 mm |
| Weight |
6.13 kg |
| Package width |
399 mm |
| Package depth |
499 mm |
| Package height |
230 mm |
| Package weight |
9 kg |
| Display included |
No |
| Mouse included |
Yes |
| Keyboard included |
Yes |
| Keyboard connectivity |
Wired |
