Description
Power to work
The ThinkCentre M75s Gen 2 desktop will breeze through your toughest tasks with up to an AMD Ryzen™ 7 PRO processor and up to 128GB DDR4 memory. Multitask, create content, and crunch data easily, improving productivity and the bottom line.
Steadfast security
The Thinkcentre M75s Gen 2 small form factor desktop’s discrete Trusted Platform Module (dTPM) chip encrypts critical information and enables hardware authentication. BIOS-based Smart USB Protection prevents unauthorized access via peripheral. And AMD GuardMI technology enables power-on-to-power-off data protection with a co-processor inside the AMD Ryzen™ PRO CPU.
Convenience guaranteed
The ThinkCentre M75s Gen 2 SFF offers plenty of convenient features to help users be more comfortable and productive. A rapid-charging USB port enables fast data transmission and device charging, even when the PC is in sleep mode. Turn on the desktop with a simple key stroke. Connect multiple peripherals to a variety of ports, for seamless multitasking. Easily manage updates, diagnostics, and security from a remote location.
Energy-efficient and reliable
The M75s Gen 2 has a minimal footprint on the environment as well as on your desk. It meets global sustainability standards for Energy Star® 8.0, EPEAT® Silver, and TCO 8.0. And it’s designed and rigorously tested for durability and reliability.
| Feature |
Feature Value |
| Processor family |
AMD Ryzen™ 5 |
| Processor manufacturer |
AMD |
| Processor model |
5600G |
| Processor frequency |
3.9 GHz |
| Processor cores |
6 |
| Processor threads |
12 |
| Processor boost frequency |
4.4 GHz |
| Processor cache |
16 MB |
| Processor cache type |
L3 |
| Number of processors installed |
1 |
| Internal memory |
8 GB |
| Maximum internal memory |
128 GB |
| Internal memory type |
DDR4-SDRAM |
| Memory layout (slots x size) |
1 x 8 GB |
| Memory slots |
4x DIMM |
| Memory clock speed |
3200 MHz |
| Memory channels |
Dual-channel |
| Total storage capacity |
256 GB |
| Optical drive type |
DVD±RW |
| Storage media |
SSD |
| Number of storage drives installed |
1 |
| Total SSDs capacity |
256 GB |
| Number of SSDs installed |
1 |
| SSD capacity |
256 GB |
| SSD interface |
PCI Express |
| NVMe |
Yes |
| SSD form factor |
M.2 |
| Card reader integrated |
Yes |
| Compatible memory cards |
SD, SDHC, SDXC |
| Discrete graphics card |
No |
| On-board graphics card |
Yes |
| Discrete graphics card model |
Not available |
| On-board graphics card model |
AMD Radeon Graphics |
| On-board GPU manufacturer |
AMD |
| Ethernet LAN |
Yes |
| Wi-Fi |
No |
| Ethernet LAN data rates |
1000,100 Mbit/s |
| Cabling technology |
10/100/1000Base-T(X) |
| Bluetooth |
No |
| USB 2.0 ports quantity |
4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
2 |
| HDMI ports quantity |
1 |
| HDMI version |
1.4b |
| DisplayPorts quantity |
2 |
| DisplayPort version |
1.4 |
| Ethernet LAN (RJ-45) ports |
1 |
| Microphone in |
Yes |
| Line-out |
Yes |
| Combo headphone/mic port |
Yes |
| Serial ports quantity |
1 |
| Chassis type |
SFF |
| Product colour |
Black |
| Volume |
8.2 L |
| Placement supported |
Vertical |
| Cable lock slot |
Yes |
| Cable lock slot type |
Kensington |
| Viewing window |
No |
| Product type |
PC |
| Motherboard chipset |
AMD PRO 565 |
| Audio chip |
Realtek ALC623-CG |
| Audio system |
High Definition Audio |
| Built-in speaker(s) |
Yes |
| Number of speakers |
1 |
| Password protection |
Yes |
| Password protection type |
Power on, Supervisor, HDD |
| Trusted Platform Module (TPM) |
Yes |
| Trusted Platform Module (TPM) version |
2.0 |
| Operating system installed |
Windows 11 Pro |
| Operating system language |
English |
| Power supply |
180 W |
| Operating temperature (T-T) |
5 – 35 °C |
| Storage temperature (T-T) |
-40 – 60 °C |
| Operating relative humidity (H-H) |
20 – 80% |
| Storage relative humidity (H-H) |
10 – 90% |
| Operating altitude |
0 – 3048 m |
| Non-operating altitude |
0 – 12192 m |
| Certification |
ErP Lot 3
MIL-STD-810H |
| Sustainability compliance |
Yes |
| Sustainability certificates |
RoHS, TCO |
| Width |
92.5 mm |
| Depth |
297.7 mm |
| Height |
339.5 mm |
| Weight |
5.3 kg |
| Display included |
No |
| Mouse included |
Yes |
| Mouse connectivity |
Wired |
| Keyboard included |
Yes |
| Keyboard connectivity |
Wired |
