Description
The leader in entry-level workstations
– The compute muscle of a workstation for the price of a desktop
– Powered by 13th Gen Intel® Core™ processors
– Choice of professional NVIDIA discrete graphics cards
– Advanced thermal design for extra power and performance
– Reliable, easy-to-deploy, & versatile, supports up to 12 displays
– ISV-certified, perfect for designers, engineers, & students
| Feature |
Feature Value |
| Processor family |
Intel® Core™ i9 |
| Processor manufacturer |
Intel |
| Processor model |
i9-13900 |
| Processor generation |
13th gen Intel® Core™ i9 |
| Processor cores |
24 |
| Performance cores |
8 |
| Efficient cores |
16 |
| Performance-core base frequency |
2 GHz |
| Efficient-core base frequency |
1.5 GHz |
| Efficient-core Max Turbo Frequency |
4.2 GHz |
| Performance-core Max Turbo Frequency |
5.2 GHz |
| Processor boost frequency |
5.6 GHz |
| Processor cache |
36 MB |
| Processor cache type |
Smart Cache |
| Processor threads |
32 |
| Bus type |
DMI4 |
| Number of processors installed |
1 |
| Processor base power |
65 W |
| Maximum turbo power |
219 W |
| Internal memory |
32 GB |
| Maximum internal memory |
128 GB |
| Internal memory type |
DDR5-SDRAM |
| Memory layout (slots x size) |
1 x 32 GB |
| Memory slots |
4x DIMM |
| Memory clock speed |
4800 MHz |
| Non-ECC |
Yes |
| Memory channels |
Dual-channel |
| Total storage capacity |
1 TB |
| Optical drive type |
No |
| Storage media |
SSD |
| Card reader integrated |
Yes |
| Number of storage drives installed |
1 |
| Total SSDs capacity |
1 TB |
| Number of SSDs installed |
1 |
| SSD capacity |
1 TB |
| SSD interface |
PCI Express 4.0 |
| NVMe |
Yes |
| SSD form factor |
M.2 |
| Compatible memory cards |
SD |
| Discrete graphics card |
No |
| On-board graphics card |
Yes |
| Discrete graphics card model |
Not available |
| On-board graphics card model |
Intel UHD Graphics 770 |
| On-board graphics card family |
Intel® UHD Graphics |
| Ethernet LAN |
Yes |
| Wi-Fi |
No |
| Ethernet LAN data rates |
100,1000 Mbit/s |
| Cabling technology |
10/100/1000Base-T(X) |
| LAN controller |
Intel® I219-LM |
| Bluetooth |
No |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
6 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
1 |
| HDMI ports quantity |
1 |
| HDMI version |
2.1 |
| DisplayPorts quantity |
2 |
| DisplayPort version |
1.4 |
| Ethernet LAN (RJ-45) ports |
1 |
| Microphone in |
Yes |
| Line-out |
Yes |
| Combo headphone/mic port |
Yes |
| Chassis type |
Tower |
| Product colour |
Black |
| Colour name |
Black |
| Volume |
27 L |
| Placement supported |
Vertical |
| Cable lock slot |
Yes |
| Cable lock slot type |
Kensington |
| Product type |
Workstation |
| Motherboard chipset |
Intel W680 |
| Audio chip |
Realtek ALC897Q-CG |
| Audio system |
High Definition Audio |
| Built-in speaker(s) |
Yes |
| Number of speakers |
1 |
| Password protection |
Yes |
| Password protection type |
BIOS, Power on, Supervisor |
| BIOS type |
UEFI |
| Trusted Platform Module (TPM) |
Yes |
| Operating system installed |
Windows 11 Pro |
| Operating system architecture |
64-bit |
| Operating system language |
English |
| CPU configuration (max) |
1 |
| Power supply |
500 W |
| Power supply input voltage |
100 – 240 V |
| Power supply input frequency |
50/60 Hz |
| 80 PLUS certification |
80 PLUS Platinum |
| Operating temperature (T-T) |
10 – 35 °C |
| Storage temperature (T-T) |
-40 – 60 °C |
| Operating relative humidity (H-H) |
20 – 80% |
| Storage relative humidity (H-H) |
10 – 90% |
| Operating altitude |
0 – 3048 m |
| Non-operating altitude |
0 – 12192 m |
| Certification |
EPEAT Gold Registered
ENERGY STAR 8.0
ErP Lot 3
TCO Certified 9.0
RoHS compliant |
| Sustainability certificates |
ENERGY STAR, TCO, EPEAT Gold, RoHS |
| Width |
180 mm |
| Depth |
370 mm |
| Height |
415 mm |
| Weight |
13.6 kg |
| Display included |
No |
| Mouse included |
Yes |
| Keyboard included |
Yes |
