Description
Redefining the power of small
– Packs amazing power into an industry-first 3.9L chassis small form factor
– Blazingly-fast Intel vProĀ® with IntelĀ® Core⢠processors, vast memory
– Choice of optional professional discrete graphics
– ISV-certified, handles complex workflows with ease
– Supports remote monitoring & system management
– Designed for compact spaces, suitable for any industry
Feature |
Feature Value |
Processor family |
Intel® Core⢠i7 |
Processor manufacturer |
Intel |
Processor model |
i7-14700 |
Processor frequency |
2.1 GHz |
Processor cores |
20 |
Processor threads |
28 |
Processor boost frequency |
5.3 GHz |
Internal memory |
16 GB |
Maximum internal memory |
128 GB |
Internal memory type |
DDR5-SDRAM |
Memory layout (slots x size) |
2 x 8 GB |
Memory slots |
4x SO-DIMM |
Memory clock speed |
4800 MHz |
Total storage capacity |
512 GB |
Optical drive type |
No |
Storage media |
SSD |
Total SSDs capacity |
512 GB |
Number of SSDs installed |
1 |
SSD capacity |
512 GB |
SSD interface |
PCI Express 4.0 |
NVMe |
Yes |
SSD form factor |
M.2 |
Discrete graphics card |
Yes |
On-board graphics card |
Yes |
Discrete graphics card model |
NVIDIA T400 |
On-board graphics card model |
Intel UHD Graphics 770 |
Discrete graphics card memory |
4 GB |
Number of discrete graphics cards |
1 |
Ethernet LAN |
Yes |
Wi-Fi |
No |
Ethernet LAN data rates |
10,100,1000 Mbit/s |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
5 |
Thunderbolt 4 ports quantity |
2 |
IntelĀ® Thunderbolt 4 |
Yes |
DisplayPorts quantity |
3 |
Ethernet LAN (RJ-45) ports |
1 |
Combo headphone/mic port |
Yes |
Cable lock slot |
Yes |
Cable lock slot type |
Kensington |
Product type |
Workstation |
Motherboard chipset |
Intel W680 |
Audio chip |
Realtek ALC897-Q |
Audio system |
High Definition Audio |
Trusted Platform Module (TPM) |
Yes |
Operating system installed |
Windows 11 Pro |
Power supply |
230 W |
Width |
87 mm |
Depth |
223 mm |
Height |
202 mm |
Weight |
3.6 kg |
Mouse included |
Yes |
Keyboard included |
Yes |
