Description
Elevate Your Game
– Hop on stream & clip highlights with Intel® Core™ processors & NVIDIA® GeForce RTX™ 40 Series graphics.
– Unleash the Lenovo AI Engine+ with LA3 & LA1 AI chips to catapult your gaming experience.
– Lenovo Legion ColdFront Hyper technology keeps your device cool & killstreaks hot.
– Choose between two Lenovo Legion PureSight Gaming display options to meet your gaming needs
– Flex control & customization on the Legion TrueStrike keyboard, lit up by Legion Spectrum.
| Feature |
Feature Value |
| Product type |
Laptop |
| Product colour |
Black |
| Form factor |
Clamshell |
| Colour name |
Eclipse Black |
| Housing material |
Aluminium |
| Display diagonal |
40.6 cm (16″) |
| Display resolution |
3200 x 2000 pixels |
| Touchscreen |
No |
| HD type |
3.2K |
| Panel type |
IPS |
| LED backlight |
Yes |
| Anti-glare screen |
Yes |
| Display brightness |
430 cd/m² |
| RGB colour space |
DCI-P3 |
| Colour gamut |
100% |
| Maximum refresh rate |
165 Hz |
| High Dynamic Range (HDR) supported |
Yes |
| High Dynamic Range (HDR) technology |
Dolby Vision |
| Processor family |
Intel® Core™ i7 |
| Processor manufacturer |
Intel |
| Processor model |
i7-14700HX |
| Processor generation |
Intel® Core™ i7 (14th gen) |
| Processor cores |
20 |
| Processor threads |
28 |
| Processor boost frequency |
5.5 GHz |
| Performance cores |
8 |
| Efficient cores |
12 |
| Performance-core Max Turbo Frequency |
5.5 GHz |
| Efficient-core Max Turbo Frequency |
3.9 GHz |
| Performance-core base frequency |
2.1 GHz |
| Efficient-core base frequency |
1.5 GHz |
| Processor cache |
33 MB |
| Processor cache type |
Smart Cache |
| Processor base power |
55 W |
| Maximum turbo power |
157 W |
| Internal memory |
32 GB |
| Maximum internal memory |
32 GB |
| Internal memory type |
DDR5-SDRAM |
| Memory clock speed |
5600 MHz |
| Memory form factor |
SO-DIMM |
| Memory layout (slots x size) |
2 x 16 GB |
| Memory slots |
2x SO-DIMM |
| Memory channels |
Dual-channel |
| Total storage capacity |
1 TB |
| Storage media |
SSD |
| Optical drive type |
No |
| Total SSDs capacity |
1 TB |
| Number of SSDs installed |
1 |
| SSD capacity |
1 TB |
| SSD interface |
PCI Express 4.0 |
| NVMe |
Yes |
| SSD form factor |
M.2 |
| Card reader integrated |
Yes |
| Compatible memory cards |
SD |
| On-board graphics card |
Yes |
| Discrete graphics card |
Yes |
| Discrete graphics card model |
NVIDIA GeForce RTX 4070 |
| On-board graphics card model |
Intel® UHD Graphics |
| Discrete GPU manufacturer |
NVIDIA |
| Discrete graphics card memory |
8 GB |
| Discrete graphics memory type |
GDDR6 |
| On-board GPU manufacturer |
Intel |
| On-board graphics card family |
Intel® UHD Graphics |
| Audio chip |
Realtek ALC3287 |
| Number of built-in speakers |
2 |
| Speaker power |
2 W |
| Built-in microphone |
Yes |
| Number of microphones |
2 |
| Front camera |
Yes |
| Front camera resolution |
1920 x 1080 pixels |
| Front camera HD type |
Full HD |
| Privacy camera |
Yes |
| Privacy type |
Privacy shutter |
| Mobile network connection |
No |
| Top Wi-Fi standard |
Wi-Fi 6E (802.11ax) |
| Wi-Fi standards |
Wi-Fi 6E (802.11ax) |
| Antenna type |
2×2 |
| Bluetooth |
Yes |
| Bluetooth version |
5.3 |
| WWAN |
Not installed |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
1 |
| HDMI ports quantity |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
1 |
| HDMI version |
2.1 |
| Thunderbolt 4 ports quantity |
1 |
| Intel® Thunderbolt 4 |
Yes |
| Combo headphone/mic port |
Yes |
| USB Sleep-and-Charge |
Yes |
| Motherboard chipset |
Intel HM770 |
| Numeric keypad |
Yes |
| Pointing device |
Touchpad |
| Keyboard language |
UK English |
| Keyboard backlit |
Yes |
| Keyboard backlit colour |
RGB |
| Keyboard backlit zone |
Per-key RGB |
| Operating system installed |
Windows 11 Home |
| Operating system architecture |
64-bit |
| Trial software |
Office |
| Battery capacity |
99.9 Wh |
| Battery technology |
Lithium Polymer (LiPo) |
| AC adapter power |
230 W |
| AC adapter frequency |
50/60 Hz |
| AC adapter input voltage |
100 – 240 V |
| Fingerprint reader |
Yes |
| Trusted Platform Module (TPM) |
Yes |
| Trusted Platform Module (TPM) version |
2.0 |
| Operating temperature (T-T) |
5 – 35 °C |
| Storage temperature (T-T) |
5 – 43 °C |
| Operating relative humidity (H-H) |
8 – 95% |
| Storage relative humidity (H-H) |
5 – 95% |
| Maximum shipping altitude |
3048 m |
| Weight |
2.24 kg |
| Width |
357.7 mm |
| Depth |
262.5 mm |
| Height (front) |
1.76 cm |
| Height (rear) |
1.98 cm |
| Mouse included |
Yes |
