Description
The KE6940A extender is consisted of a high performance IP-based transmitter (KE6940AT) that connects to the computer and a receiver (KE6940AR) that provides console access from a separate location. The KE6940A allows extended access of computer systems remotely via USB consoles (USB keyboard, USB mouse, DVI monitor) over intranet, enabling users to place the computer system in secure and temperature controlled environments, which maybe isolated from users’ workstation.
1x KE6940AT DVI-I Dual Display KVM over IP Transmitter
1x 0AD8-8005-40MA Power Adapter
1x LIN2-418K-E12G Power Cord
1x LIN5-35W1-W11G KVM Cable (DVI-D, USB, Audio; 1.8m/6ft)
1x LIN5-26W1-W11G DVI-D Cable 1.8 m
1x Foot Pad Set (4 pcs.)
1x KC06-0040-200G Mounting Kit
1x User Instructions
| Feature |
Feature Value |
| Type |
Transmitter |
| Connectivity technology |
Wired |
| Maximum transfer distance |
10000 m |
| Product colour |
Black |
| Material |
Metal |
| LED indicators |
Link, Power |
| Transmitter video port type |
DVI-I |
| Transmitter local video port |
Yes |
| Transmitter local video port type |
DVI-I |
| Number of displays supported |
2 |
| Transmitter local keyboard/mouse port type |
USB |
| RJ-45 ports quantity (transmitter) |
1 |
| AC adapter output voltage |
5 V |
| Power consumption (transmitter) (max) |
12.2 W |
| Operating temperature (T-T) |
0 – 50 °C |
| Storage temperature (T-T) |
-20 – 60 °C |
| Operating relative humidity (H-H) |
0 – 95% |
| Transmitter width |
21.5 cm |
| Transmitter depth |
16.3 cm |
| Transmitter height |
4.18 cm |
| Transmitter weight |
1.17 kg |
| Package width |
207 mm |
| Package depth |
414 mm |
| Package height |
117 mm |
| Package weight |
2.53 kg |
| Weight |
1.9 kg |
| AC adapter included |
Yes |
| Quick installation guide |
Yes |
| USB port type |
USB Type-A |
| RJ-45 ports quantity |
1 |
| PC Audio out |
Yes |
| Master (outer) case net weight |
5.7 kg |
| Harmonized System (HS) code |
84733080 |
| Master (outer) case width |
370 mm |
| Master (outer) case length |
427 mm |
| Master (outer) case height |
232 mm |
| Master (outer) case gross weight |
8.35 kg |
| Products per master (outer) case |
3 pc(s) |
