Ubiquiti UISP -FIBER-XG network media converter 10000 Mbit/s Black, White

Name: Ubiquiti UISP -FIBER-XG network media converter 10000 Mbit/s Black, White
SKU: UISP-FIBER-XG
Availability: InStock

Part No:

UISP-FIBER-XG

Price Locked for 30 Days:
Lock Added: N/A

exc VAT

£0.00

inc VAT

UISP Fiber XG-PON CPE

Non-Returnable^*

^*This item is non-returnable and non-cancellable due to customisation or built to order.

Request info below or give us a call on 0203 617 7663

SKU: UISP-FIBER-XG Category: Network Media Converters

Can't find what your looking for?

An optical network unit that can deliver 2.5Gbps uplink/10Gbps downlink speeds over distances up to 20 km.

Feature	Feature Value
Maximum data transfer rate	10000 Mbit/s
Ethernet interface type	2.5 Gigabit Ethernet, 5 Gigabit Ethernet, 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
Ethernet LAN data rates	100,1000,2500 Mbit/s
Maximum transfer distance	20000 m
Tx power (min)	2 dBmW
Tx power (max)	7 dBmW
Rx power (min)	-9 dBmW
Rx power (max)	-27 dBmW
Internal	No
Reset button	Yes
LED indicators	Yes
Product colour	Black, White
Housing material	Polycarbonate (PC)
Fiber optic connector	SC/APC
Ethernet LAN (RJ-45) ports	1
Fiber ports quantity	1
Input current	3 A
Power consumption (max)	6 W
Power over Ethernet (PoE)	Yes
Width	100 mm
Depth	100 mm
Height	27 mm
Weight	220 g
Operating temperature (T-T)	-15 – 45 °C
Operating relative humidity (H-H)	10 – 95%
Compliance certificates	CE, Federal Communications Commission (FCC), UKCA
Sustainability compliance	Yes

Maximum data transfer rate	10000 Mbit/s
Ethernet LAN data rates	100,1000,2500 Mbit/s
Tx power (min)	-2 dBmW
Rx power (min)	-9 dBmW
Internal	No
LED indicators	Yes
Housing material	Polycarbonate (PC)
Ethernet LAN (RJ-45) ports	1
Input current	3 A
Power over Ethernet (PoE)	Yes
Depth	100 mm
Weight	220 g
Sustainability compliance	Yes
Ethernet interface type	2.5 Gigabit Ethernet, 5 Gigabit Ethernet, 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
Maximum transfer distance	20000 m
Tx power (max)	7 dBmW
Rx power (max)	-27 dBmW
Reset button	Yes
Product colour	Black, White
Fiber optic connector	SC/APC
Fiber ports quantity	1
Power consumption (max)	6 W
Width	100 mm
Height	27 mm
Operating temperature (T-T)	-15 – 45 °C
Compliance certificates	CE, Federal Communications Commission (FCC), UKCA
