Description
High-performance WiFi 6 GPON CPE.
The UFiber WiFi6 GPON CPE (UF WiFi6) is a point-to-multipoint WiFi 6 device that creates high-speed GPON connections capable of reaching a 2.4 Gbps downstream rate and 1.2 Gbps upstream rate. The UF WiFi6 has (4) GbE RJ45 LAN ports and (1) GPON WAN port to connect a local fiber line. It also excels at establishing reliably strong, long-distance fiber links up to 20 kilometers, allowing you to extend your service range and build your customer base.
| Feature |
Feature Value |
| Product type |
Optical network unit (ONU) |
| Product colour |
Black |
| LED indicators |
LAN, Power |
| Networking standards |
IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| ITU standards |
G.984 |
| Ethernet LAN data rates |
1000 Mbit/s |
| Cabling technology |
10/100/1000Base-T(X) |
| Switch layer |
L2+/L3 |
| Upstream data rate |
2488 Mbit/s |
| Downstream data rate |
1244 Mbit/s |
| Transmission distance (max) |
20 km |
| Tx wavelength (max) |
1310 nm |
| Rx wavelength (max) |
1490 nm |
| VLAN support |
Yes |
| Wi-Fi |
Yes |
| Wi-Fi standards |
802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Antenna type |
Internal |
| Antenna gain level (max) |
3 dBi |
| Reset button |
Yes |
| Security algorithms |
AES, TKIP, WEP, WPA, WPA-Enterprise, WPA-PSK, WPA2, WPA3 |
| Fiber ports quantity |
1 |
| Fiber optic connector |
SC |
| Ethernet LAN (RJ-45) ports |
4 |
| USB ports quantity |
1 |
| DC-in jack |
Yes |
| Output voltage |
5 V |
| Output current |
3 A |
| Power consumption (max) |
11 W |
| Compliance certificates |
CE |
| Operating temperature (T-T) |
-15 – 45 °C |
| Operating relative humidity (H-H) |
10 – 90% |
| Width |
141.5 mm |
| Depth |
140.8 mm |
| Height |
31.6 mm |
| Weight |
415 g |
| AC adapter included |
Yes |
| Quantity per pack |
1 pc(s) |
