Description
RUT260 is a Teltonika Networks LTE Cat 6 cellular router with WAN failover. Balancing the key features of the RUT240 and RUT360, this cellular router is powerful, lightweight, and supports a wide variety of industrial protocols, including MQTT, SNMP, Modbus, and more.
| Feature |
Feature Value |
| Device type |
Cellular network router |
| Product colour |
Black, Blue |
| Housing material |
Aluminium, Plastic |
| Mounting |
DIN-rail/Wall mounting |
| Market positioning |
Industrial |
| Suitable for indoor use |
Yes |
| Built-in display |
No |
| LED indicators |
LAN, Network, Power, Signal strength, WAN |
| Ethernet LAN |
Yes |
| Ethernet LAN interface type |
Fast Ethernet |
| Ethernet LAN data rates |
10,100 Mbit/s |
| Networking standards |
IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.11r, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3u |
| DHCP client |
Yes |
| DHCP server |
Yes |
| Full duplex |
Yes |
| Wi-Fi |
Yes |
| Wi-Fi standards |
802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| WLAN data transfer rates supported |
300 Mbit/s |
| Data network |
3G, LTE |
| Number of SIM cards |
1 |
| SIM card type |
MiniSIM |
| Short Message Service (SMS) |
Yes |
| Data transfer rate (LTE) (download) |
300 Mbit/s |
| Data transfer rate (LTE) (upload) |
50 Mbit/s |
| Ethernet LAN (RJ-45) ports |
2 |
| USB port |
No |
| Security algorithms |
AES-CCMP, TKIP, WEP, WPA2-Enterprise-PEAP, WPA2-PSK, WPA3-EAP, WPA3-SAE |
| Network address translation (NAT) |
Yes |
| Firewall |
Yes |
| IP address filtering |
Yes |
| DMZ support |
Yes |
| Assisted GPS (A-GPS) |
No |
| Embedded GNSS |
No |
| GLONASS |
No |
| BeiDou |
No |
| Galileo |
No |
| Quasi-Zenith Satellite System (QZSS) |
No |
| Electronic compass |
No |
| Built-in processor |
Yes |
| Processor manufacturer |
Mediatek |
| Processor frequency |
0.58 GHz |
| RAM capacity |
0.128 GB |
| Internal storage capacity |
0.016 GB |
| Operating system installed |
RutOS |
| Web-based management |
Yes |
| GPS (satellite) |
No |
| Antenna type |
External |
| Antenna connector type |
SMA/RP-SMA |
| Antennas quantity |
3 |
| Detachable antenna(s) |
Yes |
| Power source type |
DC |
| Built-in battery |
No |
| Operating temperature (T-T) |
-40 – 75 °C |
| Operating relative humidity (H-H) |
10 – 90% |
| Width |
83 mm |
| Depth |
74 mm |
| Height |
25 mm |
| Weight |
130 g |
