Description
The HP R100 Router Series is an ideal all-in-one solution for small businesses. Part of the HP OfficeConnect portfolio, the routers delivers high-performance Internet access with both wired, wireless connectivity for remote offices and employees.
Featuring the next generation HP Networking user interface with an Easy Setup Wizard, they are designed for simplicity and reliability to get your business connected quickly, while robust security features safeguard your organization. The routers feature a compact executive design for unobtrusive use in office environments.
Features
Keep Small Business Users Connected and Productive
The HP R100 Router Series is an ideal all-in-one solution for small businesses that includes high-speed networking with a built-in, 4-port Gigabit Ethernet switch to make certain your organization has fast access to the data and files needed to get their jobs done.
Employees can stay productive while moving throughout the office with a choice of integrated IEEE 802.11n or 802.11ac wireless technology. The router series offers a choice of single radio dual band or dual radio device with 3×3 MIMO antennas that support high speeds at 5GHz and 2.4GHz.
Advanced Quality of Service (QoS) helps assure time-sensitive traffic is prioritized for reliable delivery.
Delivers excellent business productivity with reliable Internet connectivity with Gigabit Ethernet WAN interface for high-performance connectivity to the Internet, remote workers and locations.
Protects Your Organization from Unauthorized Access
The HP R100 Router Series features a Stateful Packet Inspection Firewall combined with features like WPA/WPA2 encryption, 802.1X, URL filter, Content Filters and Trusted Users Management to keep your network safe from outside threats and unauthorized access.
The series offers mobile workers and offices connectivity over the public Internet through a virtual private network (VPN), complete with enterprise-grade encryption and authentication for security.
With comprehensive time-based rules, the router series can be set to automatically connect and disconnect features such as the wireless radios, URL filters, and content filters to restrict access to specific times of day.
Easy To Use and Manage
The HP R100 Router Series introduces the next generation HP Networking Web interface design with intuitive configuration tasks, troubleshooting tools and proactive monitoring in a clean, user-friendly layout.
An Easy Setup Wizard allows users to quickly setup your network and connect your organization.
Features like email alerts, logs, Alert LED helps proactively notify users of attacks and anomalies in the network to ensure quick resolution with minimum downtime.
Flexibility that Fits Your Business
The HP R100 Router Series is future-ready with IPv6 support.
The sleek, unobtrusive design with internal wireless antennas fits well in any setting.
The Wireless Distribution System (WDS) feature allows you to scale your wireless network as your organization grows. It provides an extremely flexible and cost-effective way to link or extend wireless connectivity.
| Feature |
Feature Value |
| Ethernet WAN |
Yes |
| Wi-Fi band |
Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard |
Wi-Fi 4 (802.11n) |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g |
| Ethernet LAN |
Yes |
| Ethernet LAN interface type |
Gigabit Ethernet |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x |
| VPN tunnels quantity |
5 |
| VPN support |
y |
| Ethernet LAN (RJ-45) ports |
4 |
| Quality of Service (QoS) support |
Yes |
| Security algorithms |
WPA, WPA2 |
| Filtering |
Yes |
| MAC address filtering |
Yes |
| MAC address table |
2048 entries |
| URL filtering |
Yes |
| NAT functionality |
y |
| Processor frequency |
700 MHz |
| AC input voltage |
100 – 240 V |
| Operating temperature (T-T) |
0 – 40 °C |
| Storage temperature (T-T) |
-40 – 70 °C |
| Operating relative humidity (H-H) |
5 – 95% |
| Operating altitude |
0 – 3000 m |
| Width |
215.9 mm |
| Depth |
139.7 mm |
| Height |
38.1 mm |
| Weight |
450 g |
