Description
Aruba Instant On 1960 Switches are advanced, smart-managed, fixed configuration Gigabit stackable switches designed for small and growing businesses that are easy to deploy and affordable. These switches are designed to scale as business grows, making adding more employees, devices and applications simple. Aruba Instant On 1960 switches are made to handle today’s bandwidth-heavy applications like voice and video conferencing, enabling consistent connectivity to improve user experience and application performance. These switches come with flexible management option: local web GUI or Instant On mobile app and cloud-based web portal.
Features
High-level Gigabit with 10GbE Networking for Advanced Small Businesses
– Each model of the Aruba Instant On 1960 Switch Series includes four 10GbE connections to connect to servers, network storage devices, or to other switches.
– Two connections of 10GBASE-T deliver 10GbE over copper Category 6a cabling for simple, affordable, high-bandwidth connections to a maximum distance of 100 meters.
– With PoE models, up to 30W PoE power delivery is available for Class 4 PoE devices like access points, surveillance cameras and VoIP phones, and up to 60W PoE power delivery is available for Class 6 PoE devices like pan-tilt zoom cameras and video-enabled IP-phones.
Simplify Network Deployment and Management for Small Organizations
– The Aruba Instant On 1960 Switch series offers a complete portfolio of choices for increased small business flexibility. It consists of five models including two (2) 24-port and two (2) 48-port models in PoE and non-PoE configurations, and a 12 port 10-Gigabit aggregation switch.
– The 24-port and 48-port PoE models come with a power budget of 370W and 600W respectively to support the latest PoE-powered IoT devices.
– The Aruba Instant On 1960 Switch series can be deployed using two management modes – Instant On cloud-management (access via mobile app and/or web portal) and the local web GUI.
– Each switch has a pull-out tag, known as a luggage tag, on the front panel of the switch.
– The tag includes a QR code that includes switch ID information (SKU number, SKU name, serial number, and MAC address) for easy switch onboarding through Instant On mobile app.
Ease of Use with Cloud-Managed Stacking
– The Aruba Instant On mobile app and cloud-based web portal make cloud-managed stacking easy — just follow the recommendations to stack up to four (4) Aruba Instant On 1960 switches and manage as a single entity.
– The Aruba Instant On mobile app automatically detects members, making multiple stack members easy to setup and manage remotely.
– Automated configurations and streamlined workflows allow users to manage all stack members through one single dashboard without the need for device reboot.
Robust Security to Protect Your Network
– The Aruba Instant On 1960 Switch Series lets you use VLANs and Access Control Lists to set bounds on what data can be seen by which users.
– Leverage 802.1X with a RADIUS server to ensure only known and authorized users can access your network.
– Supports Automatic denial-of-service (DOS) monitors and protects the network against malicious attacks.
| Feature |
Feature Value |
| Switch type |
Managed |
| Switch layer |
L2+ |
| Quality of Service (QoS) support |
Y |
| Web-based management |
Y |
| Cloud-managed |
Y |
| Basic switching RJ-45 Ethernet ports quantity |
48 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| SFP+ module slots quantity |
2 |
| Networking standards |
IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3u, IEEE 802.3z |
| 10G support |
Y |
| Port mirroring |
Y |
| Full duplex |
Y |
| Flow control support |
Y |
| Link aggregation |
Y |
| Rate limiting |
Y |
| Auto MDI/MDI-X |
Y |
| Spanning tree protocol |
Y |
| Auto-sensing |
Y |
| VLAN support |
Y |
| MAC address table |
16000 entries |
| Switching capacity |
176 Gbit/s |
| Throughput |
131 Mpps |
| Latency (10-100 Mbps) |
4.4 µs |
| Latency (1 Gbps) |
2.2 µs |
| Latency (10 Gbps) |
1.1 µs |
| Jumbo frames support |
Y |
| DHCP features |
DHCP snooping |
| Access Control List (ACL) |
Y |
| IGMP snooping |
Y |
| SSH/SSL support |
Y |
| Authentication |
Port-based authentication |
| Authentication type |
RADIUS |
| Multicast support |
Y |
| IPv4 & IPv6 features |
IPv4/IPv6 access-control list (ACL) |
| IPv4 FIB entries |
32 |
| IPv6 FIB entries |
32 |
| Rack mounting |
Y |
| Stackable |
Y |
| Form factor |
1U |
| Product colour |
White |
| Physical stacking (units) |
4 |
| Built-in processor |
Y |
| Processor model |
ARM Cortex-A9 |
| Processor frequency |
800 MHz |
| Power supply included |
Y |
| AC input voltage |
100 – 240 V |
| AC input frequency |
50/60 Hz |
| Power consumption (max) |
120 W |
| Power over Ethernet (PoE) |
N |
| Operating temperature (T-T) |
0 – 40 °C |
| Storage temperature (T-T) |
-40 – 70 °C |
| Operating relative humidity (H-H) |
15 – 95% |
| Storage relative humidity (H-H) |
15 – 90% |
| Width |
442.5 mm |
| Depth |
350.5 mm |
| Height |
44 mm |
| Weight |
4.4 kg |
| Harmonized System (HS) code |
85176990 |
