Description
The KN1132VB KVM over IP switch provides local console and remote over IP access for users to monitor and access their entire data center over a network. The KN series offers superior FHD video resolution up to 1920 x 1200, virtual media transmissions at double speed, FIPS 140-2 with level 1 security standards by using an embedded FIPS 140-2 certified OpenSSL cryptographic module. Equipped with dual on-board NICs, the KN series is built to ensure reliability and availability of remote access to all servers. The KN series can be remotely accessed via WinClient / JavaClient* at a console from a separated location for management and operation. ATEN also provides an iOS app – PadClient, whose intuitive interface makes it easy to connect to the KVM over IP switch and control computers direct from user’s iPad. Please visit the PadClient webpage for more information.
This KVM switch provides out-of-band access with external modem support for BIOS-level troubleshooting when the network is down. It enables IT administrators to manage network devices (e.g. server, storage, router, and switch) in server rooms via management networks that are separate from the main / production networks. If there’s difficulty in accessing the network devices through the production network, the administrators can still access them via the KVM switch. The KVM switch offers several out-of-band access methods, such as a direct console connection from a local computer, a USB console connection from a laptop, a PSTN connection via modem, or a dedicated management network connection via the Ethernet (LAN) port.
The KN series can be integrated into ATEN’s CC2000 Centralized Management Software. The CC2000 delivers a better user experience and advanced usability. By utilizing consolidated data, task-based navigation, and simplified menus, administrators can access, configure, and manage all of the IT equipments with ease.
The KN series is compatible with ATEN’s KVM over IP Console Station – the KA82 series. The KA82 series is a standalone console that replaces PC or NB, enabling users to remotely access, monitor and control all servers connected to multiple ATEN’s KN series with impenetrable security against virus threats. It is especially suitable for environments where a PC is not allowed. In addition, the KN series works with ATEN’s PDU remote power management systems from the KVM over IP switches’ user interface.
Additional exclusive features of KN series include Message Board, Panel Array Mode, Mouse DynaSync™, and the adapter ID. ATEN KVM over IP switches save user’s time and money by allowing administrators to manage their data centers from practically anywhere – minimizing travel and MTTR (Mean Time to Repair) costs, ensuring the highest availability for data center services.
| Feature |
Feature Value |
| Number of computers controlled |
32 |
| Keyboard port type |
USB, PS/2 |
| Mouse port type |
USB, PS/2 |
| Video port type |
HDMI/VGA |
| Console ports |
HDMI, USB A, VGA (D-Sub) |
| USB 2.0 Type-B ports quantity |
1 |
| Console USB ports quantity |
2 |
| Console HDMI ports quantity |
1 |
| USB 2.0 Type-A hub ports quantity |
3 |
| Serial port type |
RJ-45 |
| Serial ports quantity |
1 |
| Audio connections |
Yes |
| Ethernet LAN |
Yes |
| Ethernet LAN (RJ-45) ports |
2 |
| HD type |
Full HD+ |
| Maximum resolution |
1920 x 1200 pixels |
| Video bandwidth |
60 Hz |
| Scan interval |
1,255 s |
| Firmware upgradeable |
Yes |
| Product colour |
Black |
| Housing material |
Metal |
| Cascadable |
Yes |
| LED indicators |
Yes |
| Push button |
Yes |
| Hot keys |
Yes |
| Power source |
AC |
| AC input voltage |
100 – 240 V |
| AC input frequency |
50/60 Hz |
| Input current |
1 A |
| Power consumption (typical) |
31.7 W |
| Operating temperature (T-T) |
0 – 40 °C |
| Storage temperature (T-T) |
-20 – 60 °C |
| Operating relative humidity (H-H) |
0 – 80% |
| Width |
412.1 mm |
| Depth |
433.6 mm |
| Height |
44 mm |
| Weight |
5.03 kg |
| Package width |
506 mm |
| Package depth |
575 mm |
| Package height |
130 mm |
| Package weight |
7.04 kg |
| Harmonized System (HS) code |
84718000 |
| Master (outer) case width |
506 mm |
| Master (outer) case length |
575 mm |
| Master (outer) case height |
130 mm |
| Master (outer) case gross weight |
7.04 kg |
| Country of origin |
Taiwan |
