ATEN 2-Port USB DVI Dual-View KVM Switch with Audio & USB 2.0 Hub (KVM cables included)

Part No:

CS1642A

Price Locked for 30 Days:
Lock Added: N/A
exc VAT
£0.00
£0.00
inc VAT
Full Product Specs
Save 5% - First order discount - Any product - Any price*
Use Promo Code: FIRST5
*This promotion may only be used once, 5% discount is applied to your first order. Can not be used in-conjunction with any other offers. Not available if paying with PayPal.

This item is currently unavailable for next day delivery, however you may still order this item as a back-order?.

2-Port USB 2.0 DVI Dual View KVMP Switch Supports two high resolution Dual Link disp

Non-Returnable*

*This item is non-returnable and non-cancellable due to customisation or built to order.

Request info below or give us a call on 0203 617 7663
SKU: CS1642A Category:

Can't find what your looking for?

Our qualified I.T. experts are here & ready to help.

Contact us on 0203 617 7663 or email us directly
Aten

Related products

Description

The CS1642A 2-Port USB DVI Dual View KVMP™ Switch is a multi-application device that integrates a 2-port KVM switch with 2-port USB hub. The newest version now supports Quad-View functionality with two Dual View KVM Switches connected.

1 x CS1642A 2-Port USB DVI Dual View KVMP™ Switch
4 x (2 x 2L-7D02UD- 2 x LIN5-26W1-W11G) Custom DVI-D Dual Link Cable Sets (1.8m)
1 x 0AD8-1605-24M1 Power Adapter
1 x User Instructions

Feature Feature Value
Number of computers controlled 2
Keyboard port type USB
Mouse port type USB
Video port type DVI-I
Console ports 3.5mm headphone, 3.5mm mic, DVI-I, USB A
DVI-I ports quantity 6
Console USB ports quantity 2
USB 2.0 Type-A hub ports quantity 2
Audio connections Yes
Headphone outputs 2
Number of microphone inputs 1
DC-in jack Yes
Ethernet LAN Yes
Ethernet LAN (RJ-45) ports 1
Maximum resolution 2560 x 1600 pixels
Video bandwidth 60 Hz
Scan interval 1,99 s
Rack mounting Yes
Product colour Black, Silver
Rack capacity 1U
Housing material Metal, Plastic
LED indicators Yes
Push button Yes
Hot keys Yes
Built-in display No
Power source DC
DC input voltage 5.3 V
Power consumption (typical) 10.6 W
Windows operating systems supported Yes
Linux operating systems supported Yes
Mac operating systems supported Yes
Other operating systems supported Yes
Sustainability certificates RoHS
Operating temperature (T-T) 0 – 50 °C
Storage temperature (T-T) -20 – 60 °C
Operating relative humidity (H-H) 0 – 80%
Width 262.3 mm
Depth 76.8 mm
Height 44 mm
Weight 1.72 kg
Package width 98 mm
Package depth 325 mm
Package height 210 mm
Package weight 2 kg
Cables included DVI, KVM
Quick installation guide Yes
Manual Yes
AC adapter included Yes
Master (outer) case net weight 8.6 kg
Harmonized System (HS) code 85176200
Master (outer) case width 342 mm
Master (outer) case length 512 mm
Master (outer) case height 232 mm
Master (outer) case gross weight 10.9 kg
Products per master (outer) case 5 pc(s)

Additional information

Mouse port type

USB
Console ports

3.5mm headphone, 3.5mm mic, DVI-I, USB A
Console USB ports quantity

2
Audio connections

Yes
Number of microphone inputs

1
Ethernet LAN

Yes
Maximum resolution

2560 x 1600 pixels
Scan interval

1,99 s
Product colour

Black, Silver
Housing material

Metal, Plastic
Push button

Yes
Built-in display

No
DC input voltage

5.3 V
Sustainability certificates

RoHS
Storage temperature (T-T)

-20 – 60 °C
Width

262.3 mm
Height

44 mm
Package width

98 mm
Package height

210 mm
Cables included

DVI, KVM
Manual

Yes
Master (outer) case width

342 mm
Master (outer) case height

232 mm
Keyboard port type

USB
Video port type

DVI-I
DVI-I ports quantity

6
Headphone outputs

2
DC-in jack

Yes
Ethernet LAN (RJ-45) ports

1
Video bandwidth

60 Hz
Rack mounting

Yes
Rack capacity

1U
LED indicators

Yes
Hot keys

Yes
Power source

DC
Power consumption (typical)

10.6 W
Operating temperature (T-T)

0 – 50 °C
Depth

76.8 mm
Weight

1.72 kg
Package depth

325 mm
Package weight

2 kg
Quick installation guide

Yes
AC adapter included

Yes
Harmonized System (HS) code

85176200
Master (outer) case length

512 mm

Brand

Aten
