ATEN 2-Port USB HDMI KVM Switch with Audio

Part No:

CS692

Price Locked for 30 Days:
Lock Added: N/A
exc VAT
£0.00
£0.00
inc VAT
Full Product Specs
Save 5% - First order discount - Any product - Any price*
Use Promo Code: FIRST5
*This promotion may only be used once, 5% discount is applied to your first order. Can not be used in-conjunction with any other offers. Not available if paying with PayPal.

This item is currently unavailable for next day delivery, however you may still order this item as a back-order?.

2 HDMI PC in 1 HDMI Monitor out with Remote Port Selector; FHD with Audio

Non-Returnable*

*This item is non-returnable and non-cancellable due to customisation or built to order.

Request info below or give us a call on 0203 617 7663
SKU: CS692 Category:

Can't find what your looking for?

Our qualified I.T. experts are here & ready to help.

Contact us on 0203 617 7663 or email us directly
Aten

Related products

Description

The CS692 2-Port USB HDMI/Audio Cable KVM Switch links two HDMI-enabled PCs or devices to a single USB keyboard, USB mouse, and HD display console. The CS692 Switch takes a giant step forward from prior cable KVM models in the Petite series, by offering full HDMI functionality, USB 2.0 peripheral sharing (via a USB hub attached to the USB mouse port), and a firmware upgrade function that allows you to keep up with latest available versions.
1x CS692 2-Port USB HDMI/Audio Cable KVM Switch with Remote Port Selector
1x User Instructions
2x Hotkey Stickers

Feature Feature Value
Number of computers controlled 2
Keyboard port type USB
Mouse port type USB
Video port type HDMI
Console ports 3.5mm headphone, 3.5mm mic, HDMI, USB A
HDMI ports quantity 2
Console USB ports quantity 2
USB 2.0 Type-A hub ports quantity 4
USB connector type USB Type-A
Audio connections Yes
Headphone outputs 3
Number of microphone inputs 3
HD type WUXGA
Maximum resolution 1920 x 1200 pixels
Video bandwidth 60 Hz
Scan interval 3,5,10,20 s
Rack mounting No
Product colour Black
Housing material Plastic
LED indicators Yes
Push button Yes
Hot keys Yes
Built-in display No
Power source DC
DC input voltage 5 V
Power consumption (typical) 0.72 W
Operating temperature (T-T) 0 – 50 °C
Storage temperature (T-T) -20 – 60 °C
Operating relative humidity (H-H) 0 – 80%
Storage relative humidity (H-H) 0 – 80%
Width 82.4 mm
Depth 66.5 mm
Height 25.2 mm
Weight 409 g
Package width 70 mm
Package depth 163 mm
Package height 235 mm
Package weight 550 g
Quick installation guide Yes
Manual Yes
Master (outer) case net weight 4.09 kg
Harmonized System (HS) code 85176200
Master (outer) case width 395 mm
Master (outer) case length 405 mm
Master (outer) case height 182 mm
Master (outer) case gross weight 6.13 kg
Products per master (outer) case 10 pc(s)

Additional information

Mouse port type

USB
Console ports

3.5mm headphone, 3.5mm mic, HDMI, USB A
Console USB ports quantity

2
USB connector type

USB Type-A
Headphone outputs

3
HD type

WUXGA
Video bandwidth

60 Hz
Rack mounting

No
Housing material

Plastic
Push button

Yes
Built-in display

No
DC input voltage

5 V
Operating temperature (T-T)

0 – 50 °C
Width

82.4 mm
Height

25.2 mm
Package width

70 mm
Package height

235 mm
Quick installation guide

Yes
Master (outer) case width

395 mm
Master (outer) case height

182 mm
Keyboard port type

USB
Video port type

HDMI
HDMI ports quantity

2
Audio connections

Yes
Number of microphone inputs

3
Maximum resolution

1920 x 1200 pixels
Scan interval

3,5,10,20 s
Product colour

Black
LED indicators

Yes
Hot keys

Yes
Power source

DC
Power consumption (typical)

0.72 W
Storage temperature (T-T)

-20 – 60 °C
Depth

66.5 mm
Weight

409 g
Package depth

163 mm
Package weight

550 g
Manual

Yes
Harmonized System (HS) code

85176200
Master (outer) case length

405 mm

Brand

Aten
