ATEN 2-Port USB HDMI KVM Switch with Audio & USB 2.0 Hub (KVM cables included)

Part No:

CS1792

Price Locked for 30 Days:
Lock Added: N/A
exc VAT
£0.00
£0.00
inc VAT
Full Product Specs
Save 5% - First order discount - Any product - Any price*
Use Promo Code: FIRST5
*This promotion may only be used once, 5% discount is applied to your first order. Can not be used in-conjunction with any other offers. Not available if paying with PayPal.

This item is currently unavailable for next day delivery, however you may still order this item as a back-order?.

2-Port USB 2.0 HDMI KVMP Switch (Cubiq)

Non-Returnable*

*This item is non-returnable and non-cancellable due to customisation or built to order.

Request info below or give us a call on 0203 617 7663
SKU: CS1792 Category:

Can't find what your looking for?

Our qualified I.T. experts are here & ready to help.

Contact us on 0203 617 7663 or email us directly
Aten

Related products

Description

With its unique design and innovative features, the CubiQ™ CS1792 USB 2.0 HDMI KVMP™ Switch provides both style and functionality for today’s multimedia SOHO environment. Combining a 2-port switch with a 2-port USB 2.0 hub, the CS1792 provides seamless HDMI signal switching between 2 PCs or other HDMI-enabled devices, such as gaming consoles, and allows users to share USB peripherals from a single console.
1x CS1792 USB 2.0 HDMI KVMP™ Switch
2x 2L-7D02UH HDMI KVM Cable Sets (1.8m)
1x LIN5-04A2-J13G Firmware Upgrade Cable
1x 0AD8-1605-24M1 Power Adapter
1x User Instructions

Feature Feature Value
Number of computers controlled 2
Keyboard port type USB
Mouse port type USB
Video port type HDMI
Console ports 3.5mm headphone, 3.5mm mic, HDMI, USB A
HDMI ports quantity 2
Console USB ports quantity 2
USB hub Yes
USB 2.0 Type-A hub ports quantity 2
USB connector type USB Type-A, USB Type-B
Audio connections Yes
Headphone outputs 4
Number of microphone inputs 4
DC-in jack Yes
HD type WUXGA
Maximum resolution 1920 x 1200 pixels
Video bandwidth 60 Hz
Scan interval 1,5,99 s
Product colour Black, Grey
Housing material Metal, Plastic
LED indicators Yes
Hot keys Yes
Built-in display No
Power source DC
DC input voltage 5.3 V
Power consumption (typical) 5.35 W
Windows operating systems supported Yes
Linux operating systems supported Yes
Mac operating systems supported Yes
Operating temperature (T-T) 0 – 50 °C
Storage temperature (T-T) -20 – 60 °C
Operating relative humidity (H-H) 0 – 80%
Storage relative humidity (H-H) 0 – 80%
Width 206.3 mm
Depth 72.4 mm
Height 44 mm
Weight 1.04 kg
Package width 95 mm
Package depth 265 mm
Package height 220 mm
Package weight 1.37 kg
Quick installation guide Yes
Manual Yes
Master (outer) case net weight 5.2 kg
Harmonized System (HS) code 85176200
Master (outer) case width 232 mm
Master (outer) case length 500 mm
Master (outer) case height 283 mm
Master (outer) case gross weight 7.3 kg
Products per master (outer) case 5 pc(s)

Additional information

Mouse port type

USB
Console ports

3.5mm headphone, 3.5mm mic, HDMI, USB A
Console USB ports quantity

2
Audio connections

Yes
Number of microphone inputs

4
HD type

WUXGA
Video bandwidth

60 Hz
Product colour

Black, Grey
LED indicators

Yes
Built-in display

No
DC input voltage

5.3 V
Storage temperature (T-T)

-20 – 60 °C
Depth

72.4 mm
Weight

1.04 kg
Package depth

265 mm
Package weight

1.37 kg
Manual

Yes
Harmonized System (HS) code

85176200
Master (outer) case length

500 mm
Keyboard port type

USB
Video port type

HDMI
HDMI ports quantity

2
USB hub

Yes
USB connector type

USB Type-A, USB Type-B
Headphone outputs

4
DC-in jack

Yes
Maximum resolution

1920 x 1200 pixels
Scan interval

1,5,99 s
Housing material

Metal, Plastic
Hot keys

Yes
Power source

DC
Power consumption (typical)

5.35 W
Operating temperature (T-T)

0 – 50 °C
Width

206.3 mm
Height

44 mm
Package width

95 mm
Package height

220 mm
Quick installation guide

Yes
Master (outer) case width

232 mm
Master (outer) case height

283 mm

Brand

Aten
