ATEN 2-Port USB HDMI Secure KVM Switch (PSD PP v4.0 Compliant)
CS1182H4
This item is currently unavailable for next day delivery, however you may still order this item as a back-order?.
2P USB Single HDMI PP4 Secure KVM
Non-Returnable*
Call Us Today! 0203 617 7663 | info@miragetek.co.uk
2P USB Single HDMI PP4 Secure KVM
Non-Returnable*
*This item is non-returnable and non-cancellable due to customisation or built to order.




ATEN PSD PP v4.0 Secure KVM Switch CS1182H4 is specifically designed to meet the stringent security requirement of secure defense and intelligence installations. ATEN PSD PP v4.0 Secure KVM Switch CS1182H4 is compliant with PSD PP v4.0 (Protection Profile for Peripheral Sharing Device, Version 4.0) standard certified by the National Information Assurance Partnership (NIAP).
ATEN PSD PP v4.0 Secure KVM Switch CS1182H4 provides isolation between computer sources and peripherals while sharing a single keyboard, mouse, monitor, and speaker set between connected computers of various security classifications. Compliance with PSD PP v4.0 ensures peripheral sharing capabilities provide maximum user data security when switching port focus, preventing unauthorized data flows or leakage between connected sources. Key protections include isolation and unidirectional data flow, restricted peripheral connectivity and filtering, user data protection, configurable device filtration and management, strict audio filtration, and always-on tamper-proof design, keeping sensitive assets isolated and providing advanced security and a user friendly design for instantly secure deployment.
To enhance security, ATEN PSD PP v4.0 Secure KVM Switch CS1182H4 only offers manual switching methods including front panel pushbuttons and Remote Port Selector (RPS) 1. With multi – layered security, ATEN PSD PP v4.0 Secure KVM Switch CS1182H4 ensures high-level desktop security and data safekeeping for applications such as government and military agencies, healthcare providers, banking and finance institutions, and other organizations that often handle sensitive or confidential data on separate networks.
| Feature | Feature Value |
|---|---|
| Number of computers controlled | 2 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | HDMI |
| Console ports | HDMI, USB A |
| HDMI ports quantity | 2 |
| USB 2.0 Type-B ports quantity | 2 |
| Console USB ports quantity | 2 |
| Console HDMI ports quantity | 1 |
| Audio connections | Yes |
| Headphone outputs | 2 |
| RJ-11 ports quantity | 1 |
| HD type | 4K Ultra HD |
| Maximum resolution | 3840 x 2160 pixels |
| Video bandwidth | 60 Hz |
| Product colour | Black |
| Housing material | Metal |
| Wired remote switch | Yes |
| LED indicators | Yes |
| Push button | Yes |
| Built-in display | No |
| Power source | AC |
| AC input voltage | 100 – 240 V |
| AC input frequency | 50 – 60 Hz |
| Input current | 1 A |
| Power consumption (typical) | 4 W |
| Operating temperature (T-T) | 0 – 50 °C |
| Storage temperature (T-T) | -20 – 60 °C |
| Operating relative humidity (H-H) | 0 – 80% |
| Width | 163.9 mm |
| Depth | 335 mm |
| Height | 44 mm |
| Weight | 1.76 kg |
| Package volume | 14724.76 cm³ |
| Package weight | 2.54 kg |
| Cables included | AC |
| Manual | Yes |
| Master (outer) case net weight | 5.88 kg |
| Master (outer) case width | 375 mm |
| Master (outer) case length | 565 mm |
| Master (outer) case height | 258 mm |
| Master (outer) case gross weight | 8.25 kg |
| Master (outer) case volume | 54651.514 cm³ |
| Country of origin | Taiwan |
| Mouse port type | USB |
|---|---|
| Console ports | HDMI, USB A |
| Console HDMI ports quantity | 1 |
| Headphone outputs | 2 |
| HD type | 4K Ultra HD |
| Video bandwidth | 60 Hz |
| Housing material | Metal |
| LED indicators | Yes |
| Built-in display | No |
| AC input voltage | 100 – 240 V |
| Input current | 1 A |
| Operating temperature (T-T) | 0 – 50 °C |
| Depth | 335 mm |
| Weight | 1.76 kg |
| Package weight | 2.54 kg |
| Manual | Yes |
| Master (outer) case width | 375 mm |
| Master (outer) case height | 258 mm |
| Master (outer) case volume | 54651.514 cm³ |
| Keyboard port type | USB |
| Video port type | HDMI |
| HDMI ports quantity | 2 |
| Console USB ports quantity | 2 |
| Audio connections | Yes |
| RJ-11 ports quantity | 1 |
| Maximum resolution | 3840 x 2160 pixels |
| Product colour | Black |
| Wired remote switch | Yes |
| Push button | Yes |
| Power source | AC |
| AC input frequency | 50/60 Hz |
| Power consumption (typical) | 4 W |
| Storage temperature (T-T) | -20 – 60 °C |
| Width | 163.9 mm |
| Height | 44 mm |
| Package volume | 14724.76 cm³ |
| Cables included | AC |
| Master (outer) case length | 565 mm |
| Country of origin | Taiwan |
