ATEN 4-Port USB 3.0 4K HDMI KVMP™ Switch with Audio Mixer Mode

Part No:

CS1824

Price Locked for 30 Days:
Lock Added: N/A
exc VAT
£0.00
£0.00
inc VAT
Full Product Specs
Save 5% - First order discount - Any product - Any price*
Use Promo Code: FIRST5
*This promotion may only be used once, 5% discount is applied to your first order. Can not be used in-conjunction with any other offers. Not available if paying with PayPal.

This item is currently unavailable for next day delivery, however you may still order this item as a back-order?.

4-Port USB 3.0 4K 60Hz HDMI KVMP Switch

Non-Returnable*

*This item is non-returnable and non-cancellable due to customisation or built to order.

Request info below or give us a call on 0203 617 7663
SKU: CS1824 Category:

Can't find what your looking for?

Our qualified I.T. experts are here & ready to help.

Contact us on 0203 617 7663 or email us directly
Aten

Related products

Description

The ATEN CS1824 KVMP™ Switch offers effortless management of four HDMI interface computers from a single USB keyboard, mouse and HDMI monitor. Supporting the most superior video quality up to 4K DCI (4096 x 2160 @ 60Hz), the CS1824 optimizes user experience of multitasking.
1x CS1824 4-Port USB 3.0 4K HDMI KVMP™ Switch
4x LIN6-19V1-V18G HDMI 2.0 Cables
4x LIN6-11C1-E12G USB 3.0 Cables
4x LIN5-0205-21CG Audio Cables
1x LIN2-418K-E12G Power Cord
1x 0AD8-8005-40MG Power Adapter
1x User Instructions

Feature Feature Value
Number of computers controlled 4
Keyboard port type USB
Mouse port type USB
Video port type HDMI
Console ports 3.5mm headphone, HDMI, USB A
HDMI ports quantity 5
HDMI version 2.0
USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity 4
Console USB ports quantity 4
USB hub Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity 2
USB connector type USB Type-A, USB Type-B
Serial ports quantity 1
Audio connections Yes
Headphone outputs 6
DC-in jack Yes
HD type 4K Ultra HD
Maximum resolution 4096 x 2160 pixels
Video bandwidth 60 Hz
Scan interval 1,99 s
HDCP Yes
Firmware upgradeable Yes
Product colour Black
Housing material Metal, Plastic
LED indicators Yes
Push button Yes
Built-in display No
Power source DC
DC input voltage 5 V
Power consumption (typical) 2.535 W
Sustainability certificates RoHS
Operating temperature (T-T) 0 – 40 °C
Storage temperature (T-T) -20 – 60 °C
Operating relative humidity (H-H) 0 – 80%
Width 88 mm
Depth 270 mm
Height 55.5 mm
Weight 2.24 kg
Package width 98 mm
Package depth 325 mm
Package height 210 mm
Package weight 2.54 kg
Master (outer) case net weight 11.2 kg
Harmonized System (HS) code 85176200
Master (outer) case width 342 mm
Master (outer) case length 512 mm
Master (outer) case height 232 mm
Master (outer) case gross weight 13.2 kg
Products per master (outer) case 5 pc(s)

Additional information

Mouse port type

USB
Console ports

3.5mm headphone, HDMI, USB A
HDMI version

2.0
Console USB ports quantity

4
Serial ports quantity

1
Headphone outputs

6
HD type

4K Ultra HD
Video bandwidth

60 Hz
HDCP

Yes
Product colour

Black
LED indicators

Yes
Built-in display

No
DC input voltage

5 V
Sustainability certificates

RoHS
Storage temperature (T-T)

-20 – 60 °C
Width

88 mm
Height

55.5 mm
Package width

98 mm
Package height

210 mm
Master (outer) case width

342 mm
Master (outer) case height

232 mm
Keyboard port type

USB
Video port type

HDMI
HDMI ports quantity

5
USB hub

Yes
USB connector type

USB Type-A, USB Type-B
Audio connections

Yes
DC-in jack

Yes
Maximum resolution

4096 x 2160 pixels
Scan interval

1,99 s
Firmware upgradeable

Yes
Housing material

Metal, Plastic
Push button

Yes
Power source

DC
Power consumption (typical)

2.535 W
Operating temperature (T-T)

0 – 40 °C
Depth

270 mm
Weight

2.24 kg
Package depth

325 mm
Package weight

2.54 kg
Harmonized System (HS) code

85176200
Master (outer) case length

512 mm

Brand

Aten
