ATEN 4-Port USB 3.1 Gen 1 DisplayPort 1.1 KVMP™ Switch with Speaker (KVM cables included)

Part No:
CS1914
Full Product Specs
Price Locked for 30 Days:
Lock Added: N/A
exc VAT
£0.00
£0.00
inc VAT
Save 5% - First order discount - Any product - Any price*
Use Promo Code: FIRST5
*This promotion may only be used once, 5% discount is applied to your first order. Can not be used in-conjunction with any other offers. Not available if paying with PayPal.

This item is currently unavailable for next day delivery, however you may still order this item as a back-order?

4-Port USB 3.0 4K 30Hz DisplayPort KVMP Switch

Non-Returnable*

*This item is non-returnable and non-cancellable due to customisation or built to order.

Request info below or give us a call on 0203 617 7663
SKU: CS1914 Category:

Can't find what your looking for?

Our qualified I.T. experts are here & ready to help.

Contact us on 0203 617 7663 or email us directly
Aten

Related products

Description

The ATEN CS1914 4-Port USB 3.0 DisplayPort KVMP™ Switch provides the latest innovations in desktop KVM switching technology to meet the increasing demand of higher video quality and file transfer rates on modern computers. The CS1914 provides superior resolutions up to 3840 x 2160 @ 30 Hz, a SuperSpeed USB 3.1 Gen 1 hub with 5 Gbps transfer rates and enhanced user-friendly operations.
1 x CS1914 4-Port USB 3.0 DisplayPort KVMP™ Switch
4 x LIN5-20K1-K14G DisplayPort Cables
4 x LIN6-11C1-E12G USB 3.0 Cables
4 x LIN5-0205-21CG Audio Cables
1 x 0AD8-8005-40MG Power Adapter
1 x User Instructions

Feature Feature Value
Number of computers controlled 4
Keyboard port type USB
Mouse port type USB
Video port type DisplayPort
Console ports USB A
DisplayPorts quantity 5
USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity 4
Console USB ports quantity 2
USB hub Yes
USB connector type USB Type-A, USB Type-B
Audio connections Yes
Headphone outputs 6
DC-in jack Yes
Maximum resolution 3840 x 2160 pixels
Automatic switching Yes
Scan interval 1,99 s
HDCP Yes
Hot-Plug support Yes
Rack mounting No
Product colour Black, Grey
Housing material Metal, Plastic
LED indicators Status, USB
Push button Yes
Hot keys Yes
Built-in display No
Output voltage 5 V
Power consumption (typical) 2.99 W
External power adapter Yes
Mac operating systems supported Yes
Sustainability certificates RoHS
Operating temperature (T-T) 0 – 50 °C
Storage temperature (T-T) -20 – 60 °C
Operating relative humidity (H-H) 0 – 80%
Width 88 mm
Depth 270 mm
Height 55.5 mm
Weight 1.97 kg
Package width 98 mm
Package depth 325 mm
Package height 210 mm
Package weight 2.46 kg
Cables included Audio (3.5mm), DisplayPort, USB
Manual Yes
AC adapter included Yes
Master (outer) case net weight 9.85 kg
Harmonized System (HS) code 85176200
Master (outer) case width 342 mm
Master (outer) case length 512 mm
Master (outer) case height 232 mm
Master (outer) case gross weight 12.8 kg
Products per master (outer) case 5 pc(s)

Additional information

Mouse port type

USB
Console ports

USB A
USB hub

Yes
Audio connections

Yes
DC-in jack

Yes
Automatic switching

Yes
HDCP

Yes
Rack mounting

No
Housing material

Metal, Plastic
Push button

Yes
Built-in display

No
Power consumption (typical)

2.99 W
Operating temperature (T-T)

0 – 50 °C
Depth

270 mm
Weight

1.97 kg
Package depth

325 mm
Package weight

2.46 kg
Manual

Yes
Master (outer) case width

342 mm
Master (outer) case height

232 mm
Keyboard port type

USB
Video port type

DisplayPort
DisplayPorts quantity

5
Console USB ports quantity

2
USB connector type

USB Type-A, USB Type-B
Headphone outputs

6
Maximum resolution

3840 x 2160 pixels
Scan interval

1,99 s
Hot-Plug support

Yes
Product colour

Black, Grey
LED indicators

Status, USB
Hot keys

Yes
Output voltage

5 V
External power adapter

Yes
Sustainability certificates

RoHS
Storage temperature (T-T)

-20 – 60 °C
Width

88 mm
Height

55.5 mm
Package width

98 mm
Package height

210 mm
Cables included

Audio (3.5mm), DisplayPort, USB
AC adapter included

Yes
Harmonized System (HS) code

85176200
Master (outer) case length

512 mm

Brand

Aten
