ATEN 8-Port CAT5e/6 KVM Over IP Switch

Part No:

KH1508AI

Price Locked for 30 Days:
Lock Added: N/A
exc VAT
£0.00
£0.00
inc VAT
Full Product Specs
Save 5% - First order discount - Any product - Any price*
Use Promo Code: FIRST5
*This promotion may only be used once, 5% discount is applied to your first order. Can not be used in-conjunction with any other offers. Not available if paying with PayPal.

This item is currently unavailable for next day delivery, however you may still order this item as a back-order?.

8 Port CAT-5 High Density KVM Switch over IP Daisy Chain

Non-Returnable*

*This item is non-returnable and non-cancellable due to customisation or built to order.

Request info below or give us a call on 0203 617 7663
SKU: KH1508AI Category:

Can't find what your looking for?

Our qualified I.T. experts are here & ready to help.

Contact us on 0203 617 7663 or email us directly
Aten

Related products

Description

The KH1508Ai Cat 5 High-Density KVM over IP Switch offers 8 computer port configurations in a 1U-high housing for convenient rack mounting. They allow local and remote operators to monitor and access the entire enterprise data center over the Internet using a web-based browser.

The KH1508Ai features RJ-45 connectors and Cat 5e/6 cable to link to the computers and supports multiplatform. This ensures that high quality signals can travel over long distance- up to 50m* without the need for KVM extenders. Utilizing KVM Adapter Cables for the final linkup, the KH1508Ai permits any combination of PCs, Macs, Sun computers, and serial devices to coexist on the installation.

In addition to TCP/IP connectivity, the KH1508Ai provides console ports for a locally attached USB or PS/2 console and a Laptop USB console (LUC) – allowing access and control from the data center as well as over the Net.
1x KH1508Ai Cat 5 High-Density KVM over IP Switch
1x Firmware Upgrade Cable
1x LIN6-04U1-M18G Laptop USB Console Cable USB-A to Micro USB-B
1x LIN2-481K-E12G Power Cord
1x Rack Mount Kit
1x Foot Pad Set (4 pcs.)
1x User Instructions

Feature Feature Value
Number of computers controlled 8
Keyboard port type USB, PS/2
Mouse port type USB, PS/2
Video port type VGA
Console ports PS/2, USB A, VGA (D-Sub)
Console USB ports quantity 2
USB hub Yes
PS/2 ports quantity 2
Ethernet LAN Yes
Ethernet LAN (RJ-45) ports 8
HD type WUXGA
Maximum resolution 1920 x 1200 pixels
Video bandwidth 60 Hz
Scan interval 1,255 s
Product colour Black
Housing material Metal
LED indicators Yes
Built-in display No
Power source AC
AC input voltage 100 – 240 V
AC input frequency 50 – 60 Hz
Input current 1 A
Power consumption (typical) 8.7 W
Operating temperature (T-T) 0 – 40 °C
Storage temperature (T-T) -20 – 60 °C
Operating relative humidity (H-H) 0 – 80%
Storage relative humidity (H-H) 0 – 80%
Width 437.2 mm
Depth 163.6 mm
Height 44 mm
Weight 3.18 kg
Package width 131 mm
Package depth 540 mm
Package height 233 mm
Package weight 3.58 kg
Quick installation guide Yes
Manual Yes
Master (outer) case net weight 9.54 kg
Harmonized System (HS) code 85176200
Master (outer) case width 420 mm
Master (outer) case length 565 mm
Master (outer) case height 258 mm
Master (outer) case gross weight 11.4 kg
Products per master (outer) case 3 pc(s)

Additional information

Mouse port type

USB, PS/2
Console ports

PS/2, USB A, VGA (D-Sub)
USB hub

Yes
Ethernet LAN

Yes
HD type

WUXGA
Video bandwidth

60 Hz
Product colour

Black
LED indicators

Yes
Power source

AC
AC input frequency

50/60 Hz
Power consumption (typical)

8.7 W
Storage temperature (T-T)

-20 – 60 °C
Depth

163.6 mm
Weight

3.18 kg
Package depth

540 mm
Package weight

3.58 kg
Manual

Yes
Harmonized System (HS) code

85176200
Master (outer) case length

565 mm
Keyboard port type

USB, PS/2
Video port type

VGA
Console USB ports quantity

2
PS/2 ports quantity

2
Ethernet LAN (RJ-45) ports

8
Maximum resolution

1920 x 1200 pixels
Scan interval

1,255 s
Housing material

Metal
Built-in display

No
AC input voltage

100 – 240 V
Input current

1 A
Operating temperature (T-T)

0 – 40 °C
Width

437.2 mm
Height

44 mm
Package width

131 mm
Package height

233 mm
Quick installation guide

Yes
Master (outer) case width

420 mm
Master (outer) case height

258 mm

Brand

Aten
