ATEN KA8270 KVM switch Rack mounting Black

Part No:

KA8270

Price Locked for 30 Days:
Lock Added: N/A
exc VAT
£0.00
£0.00
inc VAT
Full Product Specs
Save 5% - First order discount - Any product - Any price*
Use Promo Code: FIRST5
*This promotion may only be used once, 5% discount is applied to your first order. Can not be used in-conjunction with any other offers. Not available if paying with PayPal.

This item is currently unavailable for next day delivery, however you may still order this item as a back-order?.

Single Display VGA KVM over IP Console Station

Non-Returnable*

*This item is non-returnable and non-cancellable due to customisation or built to order.

Request info below or give us a call on 0203 617 7663
SKU: KA8270 Category:

Can't find what your looking for?

Our qualified I.T. experts are here & ready to help.

Contact us on 0203 617 7663 or email us directly
Aten

Related products

Description

The KVM over IP Console Station KA8270 is a standalone console that replaces PC or NB, enabling users to remotely access, monitor and control all servers connected to multiple ATEN’s KVM over IP switches* with impenetrable security against virus threats. It also supports various data encryption methods, ensuring impervious data protection. The KVM over IP Console Station can be deployed anywhere instant access is needed and stringent security required, ideal for applications such as studios, offices, data centers, broadcast stations, control rooms, or network operations centers (NOC).

The KA8270 supports USB mouse/keyboard and two USB ports for Virtual Media function, and supports 1 VGA video output at resolutions up to 1920 x 1200 @ 60 Hz.

In addition, the KVM over IP Console Station provides Panel Array Mode™ function, enabling administrators to monitor the video output of up to 64 servers simultaneously. The feature makes it possible for previewing the content of all the ports at the same time, which is especially suitable for environments such as manufacturing and surveillance that often require monitoring of a much higher number of ports.

The KVM over IP Console Station can be set on a desk, mounted on a wall or at the rear of a rack with its spacesaving 0U rack mount design. It is flexible and easy to install, and provides a GUI with multi-language interface for device management, user profile customization, as well as hassle-free configuration for large deployments.

Feature Feature Value
Keyboard port type USB
Mouse port type USB
Video port type VGA
VGA (D-Sub) ports quantity 1
USB connector type USB Type-A
Serial port type DE-9 (DB-9)
Serial ports quantity 1
Audio connections Yes
Headphone outputs 1
Number of microphone inputs 1
DC-in jack Yes
Ethernet LAN Yes
Ethernet LAN (RJ-45) ports 1
HD type Full HD+
Maximum resolution 1920 x 1200 pixels
Video bandwidth 60 Hz
Rack mounting Yes
Product colour Black
Housing material Metal
LED indicators Power
Push button Yes
Built-in display No
Power source DC
DC input voltage 5 V
Power consumption (typical) 4.66 W
Sustainability certificates RoHS
Operating temperature (T-T) 0 – 40 °C
Storage temperature (T-T) -20 – 60 °C
Operating relative humidity (H-H) 0 – 80%
Width 155.4 mm
Depth 174.2 mm
Height 28.8 mm
Weight 750 g
Cables included AC
Manual Yes
AC adapter included Yes

Additional information

Keyboard port type

USB
Video port type

VGA
USB connector type

USB Type-A
Serial ports quantity

1
Headphone outputs

1
DC-in jack

Yes
Ethernet LAN (RJ-45) ports

1
Maximum resolution

1920 x 1200 pixels
Rack mounting

Yes
Housing material

Metal
Push button

Yes
Power source

DC
Power consumption (typical)

4.66 W
Operating temperature (T-T)

0 – 40 °C
Depth

174.2 mm
Weight

750 g
Manual

Yes
Mouse port type

USB
VGA (D-Sub) ports quantity

1
Serial port type

DE-9 (DB-9)
Audio connections

Yes
Number of microphone inputs

1
Ethernet LAN

Yes
HD type

Full HD
Video bandwidth

60 Hz
Product colour

Black
LED indicators

Power
Built-in display

No
DC input voltage

5 V
Sustainability certificates

RoHS
Storage temperature (T-T)

-20 – 60 °C
Width

155.4 mm
Height

28.8 mm
Cables included

AC
AC adapter included

Yes

Brand

Aten
