ATEN Over IP Control unit (KVM + Serial), with Virtual Media Support

Part No:

CN8000A

Price Locked for 30 Days:
Lock Added: N/A
exc VAT
£0.00
£0.00
inc VAT
Full Product Specs
Save 5% - First order discount - Any product - Any price*
Use Promo Code: FIRST5
*This promotion may only be used once, 5% discount is applied to your first order. Can not be used in-conjunction with any other offers. Not available if paying with PayPal.

This item is currently unavailable for next day delivery, however you may still order this item as a back-order?.

1 port KVM over IP support PS2/USB/Serial consoles Virtual Media via USB 2.0

Non-Returnable*

*This item is non-returnable and non-cancellable due to customisation or built to order.

Request info below or give us a call on 0203 617 7663
SKU: CN8000A Category:

Can't find what your looking for?

Our qualified I.T. experts are here & ready to help.

Contact us on 0203 617 7663 or email us directly
Aten

Related products

Description

The new generation ATEN CN8000A features superior video quality with HD resolutions up to 1920 x 1200, LUC (Laptop USB Console) for easier KVM access, user-friendly local console OSD and virtual media function without additional cable.

1x CN8000A Single Port KVM over IP
1x 2L-5301UP Custom KVM Cable Set
1x LIN5-27X6-U21G Custom Console Cable Set
1x LIN5-04U1-U1LG Laptop USB Cable
1x 0AD8-1605-24M1 Power Adapter
1x Rack Mounting Kit
1x User Instructions

Feature Feature Value
Number of computers controlled 1
Keyboard port type USB, PS/2
Mouse port type USB, PS/2
Video port type VGA
Console ports USB B, VGA (D-Sub)
USB connector type Mini-USB B
Serial port type RS-232
Serial ports quantity 1
DC-in jack Yes
Ethernet LAN Yes
Ethernet LAN (RJ-45) ports 1
Security algorithms TLS
Maximum resolution 1920 x 1200 pixels
Video bandwidth 60 Hz
DDC2B support Yes
Number of users 64 user(s)
Firmware upgradeable Yes
Rack mounting Yes
Product colour Black
Housing material Metal
LED indicators Yes
Push button Yes
Built-in display No
Power source DC
DC input voltage 5.3 V
Power consumption (typical) 7.26 W
External power adapter Yes
Windows operating systems supported Yes
Linux operating systems supported Yes
Mac operating systems supported Yes
Sustainability certificates RoHS
Operating temperature (T-T) 0 – 50 °C
Storage temperature (T-T) -20 – 60 °C
Operating relative humidity (H-H) 0 – 80%
Width 81.4 mm
Depth 25 mm
Height 200 mm
Weight 1.05 kg
Package width 100 mm
Package depth 283 mm
Package height 173 mm
Package weight 1.23 kg
Cables included USB
Manual Yes
AC adapter included Yes
Rack mount kit Yes
Master (outer) case net weight 5.25 kg
Harmonized System (HS) code 85176200
Master (outer) case width 292 mm
Master (outer) case length 517 mm
Master (outer) case height 194 mm
Master (outer) case gross weight 6.66 kg
Products per master (outer) case 5 pc(s)

Additional information

Mouse port type

USB, PS/2
Console ports

USB B, VGA (D-Sub)
Serial port type

RS-232
DC-in jack

Yes
Ethernet LAN (RJ-45) ports

1
Maximum resolution

1920 x 1200 pixels
DDC2B support

Yes
Firmware upgradeable

Yes
Product colour

Black
LED indicators

Yes
Built-in display

No
DC input voltage

5.3 V
External power adapter

Yes
Sustainability certificates

RoHS
Storage temperature (T-T)

-20 – 60 °C
Width

81.4 mm
Height

200 mm
Package width

100 mm
Package height

173 mm
Cables included

USB
AC adapter included

Yes
Master (outer) case width

292 mm
Master (outer) case height

194 mm
Keyboard port type

USB, PS/2
Video port type

VGA
USB connector type

Mini-USB B
Serial ports quantity

1
Ethernet LAN

Yes
Security algorithms

TLS
Video bandwidth

60 Hz
Number of users

64 user(s)
Rack mounting

Yes
Housing material

Metal
Push button

Yes
Power source

DC
Power consumption (typical)

7.26 W
Operating temperature (T-T)

0 – 50 °C
Depth

25 mm
Weight

1.05 kg
Package depth

283 mm
Package weight

1.23 kg
Manual

Yes
Rack mount kit

Yes
Harmonized System (HS) code

85176200
Master (outer) case length

517 mm

Brand

Aten
