ATEN Single Port KVM over IP Switch with Single Port Power Switch

Part No:

KN1000A

Price Locked for 30 Days:
Lock Added: N/A
exc VAT
£0.00
£0.00
inc VAT
Full Product Specs
Save 5% - First order discount - Any product - Any price*
Use Promo Code: FIRST5
*This promotion may only be used once, 5% discount is applied to your first order. Can not be used in-conjunction with any other offers. Not available if paying with PayPal.

This item is currently unavailable for next day delivery, however you may still order this item as a back-order?.

1 port KVM Over the NET with Virtual media Remote power on/off/reset and schedule management

Non-Returnable*

*This item is non-returnable and non-cancellable due to customisation or built to order.

Request info below or give us a call on 0203 617 7663
SKU: KN1000A Category:

Can't find what your looking for?

Our qualified I.T. experts are here & ready to help.

Contact us on 0203 617 7663 or email us directly
Aten

Related products

Description

ATEN’s new KN1000A Single Port KVM over IP Switch provides access and control “over-IP” for conventional KVM switches and servers that do not have built-in over-IP functionality. It allows system operators to monitor and access computers from remote locations for “down to the BIOS-level” troubleshooting, using standard Web browsers or Windows and Java based application programs, without the need to be on site for constant IT maintenance. In addition, the KN1000A supports out-of-band access in case the LAN goes down, with external modem support as backup.

1 x KN1000A Single Port KVM over IP Switch
1 x 2L-5301UP Custom KVM Cable Sets
1 x LIN5-27X6-U21G Custom Console Cable Set
1 x LIN6-04U1-M18G Mini USB to Type A USB Cable
1 x 0AD8-1605-24M1 Power Adapter
1 x LIN2-418K-P13G Outlet Power Cord
1 x Mounting Kit
1 x User Instructions

Feature Feature Value
Number of computers controlled 1
Keyboard port type No
Mouse port type No
Video port type VGA
Console ports SPHD, USB B
USB connector type Mini-USB B
DC-in jack Yes
Ethernet LAN Yes
Ethernet LAN (RJ-45) ports 1
HD type WUXGA
Maximum resolution 1920 x 1200 pixels
DDC2B support Yes
Number of users 54 user(s)
Product colour Black
Housing material Metal
LED indicators Yes
Built-in display No
Power source AC
AC input voltage Hög videoupplösning – upp till 1920 x 1200 vid 60 Hz med 24-bitars färgdjup för den lokala konsolen; upp till 1920 x 1200 vid 60 Hz med 24-bitars färgdjup för fjärrsessioner Notera: * Kompatibla KVM-switchar inkluderar följande: CS9134, CS9138, CS1308, CS1316, CS1754, CS1758, CS1708A, CS1716A, ACS1208A, ACS1216A, KH2508A, KH2516A, KH1508A och KH1516A (vissa av funktionerna i KN1000A kanske inte stöds, beroende på funktionaliteten i den anslutna KVM-switchen. Till exempel stödjer inte alla switchar virtuell media). Vissa funktioner i de anslutna KVM-switcharna kanske inte stöds i KN1000A. (Till exempel ljudet i CS1754.) ** Kräver en CV130A-converter Stödjer TLS 1.2-datakryptering och 2048 bitars RSA-certifikat för att säkra användarinloggningar som sker via webbläsare Stöd för virtuell media
AC input frequency 50 – 60 Hz
Input current 10 A
Output voltage 100 – 240 V
Output current 9 A
Sustainability certificates RoHS
Operating temperature (T-T) 0 – 50 °C
Storage temperature (T-T) -20 – 60 °C
Operating relative humidity (H-H) 0 – 80%
Width 83.9 mm
Depth 310 mm
Height 42 mm
Weight 1.61 kg
Package width 207 mm
Package depth 414 mm
Package height 117 mm
Package weight 2.03 kg
Master (outer) case net weight 4.84 kg
Harmonized System (HS) code 85176200
Master (outer) case width 370 mm
Master (outer) case length 427 mm
Master (outer) case height 232 mm
Master (outer) case gross weight 6.89 kg
Products per master (outer) case 3 pc(s)

Additional information

Mouse port type

No
Console ports

SPHD, USB B
DC-in jack

Yes
Ethernet LAN (RJ-45) ports

1
Maximum resolution

1920 x 1200 pixels
Number of users

54 user(s)
Housing material

Metal
Built-in display

No
AC input voltage
Input current

10 A
Output current

9 A
Operating temperature (T-T)

0 – 50 °C
Depth

310 mm
Weight

1.61 kg
Package depth

414 mm
Package weight

2.03 kg
Harmonized System (HS) code

85176200
Master (outer) case length

427 mm
Keyboard port type

No
Video port type

VGA
USB connector type

Mini-USB B
Ethernet LAN

Yes
HD type

WUXGA
DDC2B support

Yes
Product colour

Black
LED indicators

Yes
Power source

AC
AC input frequency

50/60 Hz
Output voltage

100-240 V
Sustainability certificates

RoHS
Storage temperature (T-T)

-20 – 60 °C
Width

83.9 mm
Height

42 mm
Package width

207 mm
Package height

117 mm
Master (outer) case width

370 mm
Master (outer) case height

232 mm

Brand

Aten
