Mellanox Technologies MMA1B00-E100 network transceiver module Fiber optic 100000

Part No:
980-9I17L-00E000
Full Product Specs
Price Locked for 30 Days:
Lock Added: N/A
exc VAT
£545.94
£655.13
inc VAT
Save 5% - First order discount - Any product - Any price*
Use Promo Code: FIRST5
*This promotion may only be used once, 5% discount is applied to your first order. Can not be used in-conjunction with any other offers. Not available if paying with PayPal.

This item is currently unavailable for next day delivery, however you may still order this item as a back-order?

NVIDIA – QSFP28 transceiver module – 100 Gigabit InfiniBand – 100GBase-SR4 – MPO-12/UPC multi-mode – up to 100 m – 850 nm

Available on back-order

Non-Returnable*

Safe & Secure shopping

*This item is non-returnable and non-cancellable due to customisation or built to order.

SKU: 980-9I17L-00E000 Category:

Can't find what your looking for?

Our qualified I.T. experts are here & ready to help.

Contact us on 0203 617 7663 or email us directly
NVIDIA

Related products

Description

Mellanox MMA1B00-E100 Transceiver IB EDR up to 100Gb/s QSFP28 MPO 850nm SR4 up to 100m

The MMA1B00-E100 is a 4-channel, pluggable, QSFP28 optical transceiver, designed for use in EDR 100Gb/s InfiniBand. This module incorporates Mellanox integrated circuit technology, to provide high performance at low power. The transceiver operates over parallel multi-mode (MMF) ribbon fiber, using a nominal wavelength of 850nm, and is SFF-8665 compliant. The MMA1B00-E100 has a standard QSFP28 connector on the electrical side towards the host system supporting CAUI-4. The optical interface is composed of four optical channels/fibers in each direction, intended for a parallel multi-mode optical cable via a standard MPO connector. Each channel/fiber operates at signaling rates up to 25.78125 GBd.

Feature Feature Value
SFP transceiver type Fiber optic
Maximum data transfer rate 100000 Mbit/s
Interface type QSFP28
Multi-mode fiber (MMF) supported Yes
Maximum transfer distance 100 m
Wavelength 850 nm
Product colour Metallic
Input voltage 4 V
Compliance certificates RoHS
Operating temperature (T-T) 0 – 70 °C
Storage temperature (T-T) -40 – 85 °C
Operating relative humidity (H-H) 5 – 85%
Width 18.3 mm
Depth 118 mm
Height 8.5 mm

Additional information

SFP transceiver type

Fiber optic
Interface type

QSFP28
Maximum transfer distance

100 m
Product colour

Metallic
Compliance certificates

RoHS
Storage temperature (T-T)

-40 – 85 °C
Width

18.3 mm
Height

8.5 mm
Maximum data transfer rate

100000 Mbit/s
Wavelength

850 nm
Input voltage

4 V
Operating temperature (T-T)

0 – 70 °C
Depth

118 mm

Brand

NVIDIA
