Description
Explore the Switch Series
Your network is under more pressure than ever. As the number of connected devices expands, bandwidth demands continue to soar, making it difficult to consistently provide the secure, high-speed connection your business depends on.
SonicWall’s feature-rich switches answer the challenge delivering high-speed switching, so you can add more devices, keep up with SaaS proliferation and gain more control, all while protecting your network and your budget.
Its unified security posture makes it ideal for small and medium-sized businesses and Software Defined Branch (SD-Branch) deployments. Keep pace with the changing network and security landscape.
SD-Branch Ready
Integrates seamlessly with the SonicWall ecosystem to provide unified security posture.
10 Gigabit Connectivity
Attain significant boost in your overall switching performance as network demands grow.
Simplified Management
Whether through the firewall or cloud, with our single-pane-of-glass view, managing your security is easy.
Zero-Touch Deployment
Quickly set up, configure and deploy devices without the time and expense of site visits or on-site personnel.
Flexible Deployment Options
Multiple models provide you the flexibility to choose the best option aligned with your business goals.
Stackable Switch
Allows you to daisy chain multiple switches to enhance simplicity and scalability.
| Feature |
Feature Value |
| Switch type |
Managed |
| Switch layer |
L2 |
| System event log |
Yes |
| MIB support |
MIB-II |
| Basic switching RJ-45 Ethernet ports quantity |
8 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| SFP module slots quantity |
2 |
| Networking standards |
IEEE 802.1ab, IEEE 802.1p, IEEE 802.1x |
| 10G support |
No |
| Copper ethernet cabling technology |
10BASE-T, 100BASE-TX, 1000BASE-LX, 1000BASE-SX, 1000BASE-T |
| Port mirroring |
Yes |
| IP routing |
Yes |
| Auto MDI/MDI-X |
Yes |
| VLAN support |
Yes |
| Virtual LAN features |
Tagged VLAN |
| Number of VLANs |
4096 |
| MAC address table |
8000 entries |
| Switching capacity |
20 Gbit/s |
| Jumbo frames support |
Yes |
| DHCP features |
DHCP client, DHCP relay, DHCP snooping |
| IGMP snooping |
Yes |
| Security algorithms |
802.1x RADIUS, HTTPS, SNMP, SSH |
| Multicast support |
Yes |
| Product colour |
Black |
| LED indicators |
Fault, Power |
| Certification |
FCC Class A, ICES Class A, CE (EMC Class A, LVD, RoHS), C-Tick, VCCI Class A, UL cUL, TUV/GS, CB, Mexico UL DGN notification, WEEE, REACH, BSMI, KCC/MSIP, ANATEL |
| Internal memory |
256 MB |
| Flash memory |
32 MB |
| Mean time between failures (MTBF) |
1387712 h |
| Power supply included |
Yes |
| DC input voltage |
12 V |
| Input current |
2 A |
| Power consumption (max) |
5.7 W |
| Power over Ethernet (PoE) |
No |
| Operating temperature (T-T) |
0 – 40 °C |
| Storage temperature (T-T) |
-40 – 70 °C |
| Operating relative humidity (H-H) |
10 – 95% |
| Heat dissipation |
19.4 BTU/h |
| Width |
240 mm |
| Depth |
27 mm |
| Height |
105 mm |
| Weight |
620 g |
| Harmonized System (HS) code |
85176990 |
