TP-Link JetStream 16-Port Gigabit Easy Smart
This item is currently unavailable for next day delivery, however you may still order this item as a back-order?
Description
Ideal for Surveillance
TL-SG1218MPE complies with the 802.3af/at PoE+ standard, supporting up to 30W power supply on each PoE port. The total high PoE power budget is up to 192W for the 16 PoE ports, making it ideal for small to medium business surveillance systems.
Intelligent Power Management
When total power consumption excels 192W, the intelligent power management will cut the lower priority port power off to ensure the high priority port’s power supply and protect the device from power overload operation.
Making Management Easy
TL-SG1218MPE offers network monitoring for users to observe traffic behavior. Through its web-based user interface and management utility, the TL-SG1218MPE offers a variety of useful features, including network monitoring, traffic prioritization, and enhanced QoS.
FeatureFeature Value
Switch type | Managed |
Switch layer | L2 |
Quality of Service (QoS) support | Yes |
Web-based management | Yes |
Basic switching RJ-45 Ethernet ports quantity | 16 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Gigabit Ethernet (copper) ports quantity | 16 |
SFP module slots quantity | 2 |
Networking standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x |
10G support | No |
Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
Cable types supported | Cat3, Cat4, Cat5, Cat5e, Cat6 |
Port mirroring | Yes |
Flow control support | Yes |
Link aggregation | Yes |
Broadcast storm control | Yes |
Auto MDI/MDI-X | Yes |
Auto-negotiation | Yes |
VLAN support | Yes |
Virtual LAN features | Port-based VLAN |
Number of VLANs | 32 |
Fiber ethernet cabling technology | 1000BASE-X |
MAC address table | 8000 entries |
Switching capacity | 36 Gbit/s |
Forwarding rate | 23.8 Mpps |
Store-and-forward | Yes |
Number of queues | 4 |
Jumbo frames support | Yes |
Jumbo frames | 9000 |
Packet buffer memory | 4.1 MB |
IGMP snooping | Yes |
Rack mounting | Yes |
Form factor | 1U |
Product colour | Black |
Number of fans | 2 fan(s) |
Certification | CE, FCC, RoHS |
Power source | AC |
Power supply included | Yes |
AC input voltage | 100 – 240 V |
AC input frequency | 50 – 60 Hz |
Power consumption (max) | 217.22 W |
Power over Ethernet (PoE) | Yes |
Power over Ethernet plus (PoE+) ports quantity | 16 |
Total Power over Ethernet (PoE) budget | 192 W |
Operating temperature (T-T) | 0 – 50 °C |
Storage temperature (T-T) | -40 – 70 °C |
Operating relative humidity (H-H) | 10 – 90% |
Storage relative humidity (H-H) | 5 – 90% |
Heat dissipation | 741.15 BTU/h |
Width | 440 mm |
Depth | 180 mm |
Height | 44 mm |
Cables included | AC |
User guide | Yes |
Rack mount kit | Yes |
Package width | 528 mm |
Package depth | 250 mm |
Package height | 80 mm |
Package weight | 2.91 kg |
Harmonized System (HS) code | 85176990 |
Additional information
Switch type | Managed |
---|---|
Networking standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x |
Port mirroring | Yes |
Link aggregation | Yes |
Auto MDI/MDI-X | Yes |
VLAN support | Yes |
Number of VLANs | 32 |
MAC address table | 8000 entries |
Forwarding rate | 23.8 Mpps |
Number of queues | 4 |
Jumbo frames | 9000 |
IGMP snooping | Yes |
Form factor | 1U |
Number of fans | 2 fan(s) |
Power source | AC |
AC input voltage | 100 – 240 V |
Power consumption (max) | 217.22 W |
Operating temperature (T-T) | 0 – 50 °C |
Heat dissipation | 741.15 BTU/h |
Depth | 180 mm |
Cables included | AC |
Rack mount kit | Yes |
Package depth | 250 mm |
Package weight | 2.91 kg |
Switch layer | L2 |
Web-based management | Yes |
SFP module slots quantity | 2 |
10G support | No |
Cable types supported | Cat3, Cat4, Cat5, Cat5e, Cat6 |
Flow control support | Yes |
Broadcast storm control | Yes |
Auto-negotiation | Yes |
Virtual LAN features | Port-based VLAN |
Switching capacity | 36 Gbit/s |
Store-and-forward | Yes |
Jumbo frames support | Yes |
Packet buffer memory | 4.1 MB |
Rack mounting | Yes |
Product colour | Black |
Certification | CE, FCC, RoHS |
Power supply included | Yes |
AC input frequency | 50/60 Hz |
Power over Ethernet (PoE) | Yes |
Storage temperature (T-T) | -40 – 70 °C |
Width | 440 mm |
Height | 44 mm |
User guide | Yes |
Package width | 528 mm |
Package height | 80 mm |
Harmonized System (HS) code | 85176990 |
