Ubiquiti UniFi ECS-24-POE network switch Managed L2/L3 10G Ethernet (100/1000/10

Part No:
ECS-24-POE
Full Product Specs
Price Locked for 30 Days:
Lock Added: N/A
exc VAT
£2,071.46
£2,485.75
inc VAT
Save 5% - First order discount - Any product - Any price*
Use Promo Code: FIRST5
*This promotion may only be used once, 5% discount is applied to your first order. Can not be used in-conjunction with any other offers. Not available if paying with PayPal.
Last few available! Order now: Only 3 left.

Ubiquiti

3 in stock (can be backordered)

Non-Returnable*

Safe & Secure shopping

*This item is non-returnable and non-cancellable due to customisation or built to order.

SKU: ECS-24-POE Category:

Can't find what your looking for?

Our qualified I.T. experts are here & ready to help.

Contact us on 0203 617 7663 or email us directly
Ubiquiti Networks

Related products

Description

Enterprise-grade 24-port, Layer 3 Etherlighting™ PoE+++ switch with high-capacity 10 GbE RJ45 and 25G SFP28 connections for high availability system design.

Feature Feature Value
Switch type Managed
Switch layer L2/L3
Basic switching RJ-45 Ethernet ports quantity 24
Basic switching RJ-45 Ethernet ports type 10G Ethernet (100/1000/10000)
2.5G Ethernet (copper) ports quantity 8
10G Ethernet (copper) ports quantity 16
SFP module slots quantity 2
SFP28 ports quantity 2
Power connector AC-in jack
Networking standards IEEE 802.1x, IEEE 802.3bt
10G support Yes
Port mirroring Yes
Flow control support Yes
Link aggregation Yes
Broadcast storm control Yes
Rate limiting Yes
Ethernet LAN data rates 10,100,1000,2500,5000,10000 Mbit/s
IPv4 routes 256000
VLAN support Yes
Virtual LAN features Voice VLAN
MAC address table 128000 entries
Switching capacity 460 Gbit/s
Throughput 230 Gbit/s
Forwarding rate 342.24 Mpps
Static route Yes
Jumbo frames support Yes
Packet buffer memory 8 MB
DHCP features DHCP guarding, DHCP relay, DHCP snooping
IGMP snooping Yes
Loop protection Yes
Multicast support Yes
Rack mounting Yes
Form factor 1U
Product colour Grey
Housing material SGCC
Reset button Yes
LED indicators Activity, Link, Status
Redundant fans support Yes
Display type LCM
Number of fans 4 fan(s)
Power source AC
Power supply included Yes
Redundant power supply (RPS) support Yes
Number of power supply units 2
AC input voltage 100 – 240 V
AC input frequency 50/60 Hz
Power consumption (max) 2400 W
Power over Ethernet (PoE) Yes
Power over Ethernet (PoE) type supported PoE+, PoE++ (4PPoE)
Power over Ethernet (PoE) power per port 90 W
Total Power over Ethernet (PoE) budget 1050 W
Operating temperature (T-T) -5 – 40 °C
Operating relative humidity (H-H) 10 – 90%
Width 442.4 mm
Depth 496 mm
Height 43.7 mm
Weight 9.46 kg
Cables included Power
Rack mount kit Yes
Rack rails Yes
Mounting brackets included Yes
Compliance certificates CE, Federal Communications Commission (FCC), Industry Canada (IC), National Defense Authorization Act (NDAA)

Additional information

Switch type

Managed
SFP module slots quantity

2
Power connector

AC-in jack
10G support

Yes
Flow control support

Yes
Broadcast storm control

Yes
Ethernet LAN data rates

10,100,1000,2500,5000,10000 Mbit/s
VLAN support

Yes
MAC address table

128000 entries
Throughput

230 Gbit/s
Static route

Yes
Packet buffer memory

8 MB
IGMP snooping

Yes
Multicast support

Yes
Form factor

1U
Housing material

SGCC
LED indicators

Activity, Link, Status
Display type

LCM
Power source

AC
AC input voltage

100 – 240 V
Power consumption (max)

2400 W
Depth

496 mm
Weight

9.46 kg
Rack mount kit

Yes
Mounting brackets included

Yes
Switch layer

L2/L3
SFP28 ports quantity

2
Networking standards

IEEE 802.1x, IEEE 802.3bt
Port mirroring

Yes
Link aggregation

Yes
Rate limiting

Yes
IPv4 routes

256000
Virtual LAN features

Voice VLAN
Switching capacity

460 Gbit/s
Forwarding rate

342.24 Mpps
Jumbo frames support

Yes
DHCP features

DHCP guarding, DHCP relay, DHCP snooping
Loop protection

Yes
Rack mounting

Yes
Product colour

Grey
Reset button

Yes
Redundant fans support

Yes
Number of fans

4 fan(s)
Power supply included

Yes
AC input frequency

50/60 Hz
Power over Ethernet (PoE)

Yes
Operating temperature (T-T)

-5 – 40 °C
Width

442.4 mm
Height

43.7 mm
Cables included

Power
Rack rails

Yes
Compliance certificates

CE, Federal Communications Commission (FCC), Industry Canada (IC), National Defense Authorization Act (NDAA)

Brand

Ubiquiti Networks
