ATEN HDMI HDBaseT Small Factor Extender

Part No:

VE811

Price Locked for 30 Days:
Lock Added: N/A
exc VAT
£0.00
£0.00
inc VAT
Full Product Specs
Save 5% - First order discount - Any product - Any price*
Use Promo Code: FIRST5
*This promotion may only be used once, 5% discount is applied to your first order. Can not be used in-conjunction with any other offers. Not available if paying with PayPal.

This item is currently unavailable for next day delivery, however you may still order this item as a back-order?.

VE811-AT-E HDBaseT Extender Kit

Non-Returnable*

*This item is non-returnable and non-cancellable due to customisation or built to order.

Request info below or give us a call on 0203 617 7663
SKU: VE811 Category:

Can't find what your looking for?

Our qualified I.T. experts are here & ready to help.

Contact us on 0203 617 7663 or email us directly
Aten

Related products

Description

The ATEN VE811 HDMI HDBaseT Extender guarantees the optimum HDMI connection up to 100 m over a single Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable. The VE811 meets HDMI Specification features including 3D, Deep Color, HD lossless audio formats and CEC pass-through. It supports Dolby Digital 5.1, DTS HD audio and video signals at resolutions up to 4K. In addition, the VE811 supports long reach mode, providing an effective means for extending HDMI signals up to 150m over a single Cat 5e/6 cable.
1x VE811T HDMI HDBaseT Transmitter
1x VE811R HDMI HDBaseT Receiver
2x 0AD6-1F05-26EG Power Adapters
1x User Instructions

Feature Feature Value
Type AV transmitter & receiver
Maximum resolution 4096 x 2160 pixels
Cable types supported Cat5e, Cat6, Cat6a
Maximum transfer distance 150 m
Bandwidth 10.2 Gbit/s
Bandwidth 340 MHz
HDCP Yes
Material Metal
Impedance 100 Ω
Product colour Black
Connectivity technology Wired
RJ-45 input ports 1
RJ-45 output ports 1
HDMI in 1
Number of HDMI outputs 1
Audio input 1
Audio output 1
DC-in jack Yes
Operating voltage (transmitter) 5 V
Operating voltage (receiver) 5 V
Operating temperature (T-T) 0 – 40 °C
Storage temperature (T-T) -20 – 60 °C
Operating relative humidity (H-H) 0 – 80%
Storage relative humidity (H-H) 0 – 80%
Weight 630 g
Receiver dimensions (WxDxH) 86.4 x 73 x 24.7 mm
Receiver weight 170 g
Transmitter dimensions (WxDxH) 86.4 x 73 x 24.7 mm
Transmitter weight 160 g
Quantity per pack 2 pc(s)
Package width 59 mm
Package depth 239 mm
Package height 160 mm
Package weight 705 g
Quick start guide Yes
Master (outer) case width 250 mm
Master (outer) case length 325 mm
Master (outer) case height 175 mm
Master (outer) case gross weight 4.02 kg
Master (outer) case net weight 3.15 kg
Products per master (outer) case 5 pc(s)

Additional information

Type

AV transmitter & receiver
Cable types supported

Cat5e, Cat6, Cat6a
HDCP

Yes
Impedance

100 Ω
Connectivity technology

Wired
RJ-45 output ports

1
Number of HDMI outputs

1
Audio output

1
Operating temperature (T-T)

0 – 40 °C
Weight

630 g
Receiver weight

170 g
Transmitter weight

160 g
Package width

59 mm
Package height

160 mm
Quick start guide

Yes
Master (outer) case length

325 mm
Maximum resolution

4096 x 2160 pixels
Maximum transfer distance

150 m
Bandwidth

10.2 Gbit/s, 340 MHz
Material

Metal
Product colour

Black
RJ-45 input ports

1
HDMI in

1
Audio input

1
DC-in jack

Yes
Storage temperature (T-T)

-20 – 60 °C
Receiver dimensions (WxDxH)

86.4 x 73 x 24.7 mm
Quantity per pack

2 pc(s)
Package depth

239 mm
Package weight

705 g
Master (outer) case width

250 mm
Master (outer) case height

175 mm

Brand

Aten
