ATEN VE805R-AT-E AV extender AV receiver Black

Part No:
VE805R-AT-E
Full Product Specs
Price Locked for 30 Days:
Lock Added: N/A
exc VAT
£351.43
£421.72
inc VAT
Save 5% - First order discount - Any product - Any price*
Use Promo Code: FIRST5
*This promotion may only be used once, 5% discount is applied to your first order. Can not be used in-conjunction with any other offers. Not available if paying with PayPal.

This item is currently unavailable for next day delivery, however you may still order this item as a back-order?

VE805R-AT-E HDBaseT Lite Receiver over single Cat 5, Scaler built-in

Available on back-order

Non-Returnable*

Safe & Secure shopping

*This item is non-returnable and non-cancellable due to customisation or built to order.

SKU: VE805R-AT-E Category:

Can't find what your looking for?

Our qualified I.T. experts are here & ready to help.

Contact us on 0203 617 7663 or email us directly
Aten

Related products

Description

The VE805R HDMI HDBaseT-Lite Receiver with Scaler can be combined with ATEN HDMI HDBaseT products to extend your HDMI display up to 60 m from your HDMI source device using a single Cat 5e/6a cable.

With a built-in scaler, the VE805R supports scaling the display of different video resolutions. When combined with the ATEN VM8514 HDBaseT Output Board, it supports video wall integration and Seamless Switch™ functions. In addition, the VE805R is equipped with RS-232 and IR signaling pass-through, which allows RS-232 and IR channels to be controlled either from the remote to local unit or from the local to remote unit, for bi-directional control of the source or display device.

Feature Feature Value
Type AV receiver
Maximum resolution 1920 x 1080 pixels
Cable types supported Cat5e, Cat6, Cat6a
Maximum transfer distance 70 m
RS-232 pass-through Yes
Supported video modes 1080p
Bandwidth 6.75 Gbit/s
Bandwidth 225 MHz
On/off switch Yes
HDCP Yes
Material Metal
Wall mountable Yes
Impedance 100 Ω
HDCP version 1.4
Product colour Black
Connectivity technology Wired
Ethernet LAN Yes
RJ-45 input ports 1
Number of HDMI outputs 1
HDMI version 1.4
RS-232 input ports 1
Remote (IR) input 1
DC-in jack Yes
Power source type DC
Operating voltage 5 V
Power consumption (typical) 9.5 W
Operating temperature (T-T) 0 – 50 °C
Storage temperature (T-T) -20 – 60 °C
Operating relative humidity (H-H) 0 – 80%
Receiver dimensions (WxDxH) 169.2 x 181.8 x 42 mm
Receiver weight 830 g
Quantity per pack 1 pc(s)

Additional information

Type

AV receiver
Cable types supported

Cat5e, Cat6, Cat6a
RS-232 pass-through

Yes
On/off switch

Yes
Material

Metal
Impedance

100 Ω
Product colour

Black
Ethernet LAN

Yes
Number of HDMI outputs

1
RS-232 input ports

1
DC-in jack

Yes
Operating voltage

5 V
Operating temperature (T-T)

0 – 50 °C
Receiver weight

830 g
Maximum resolution

1920 x 1080 pixels
Maximum transfer distance

70 m
Supported video modes

1080p
Bandwidth

225 MHz, 6.75 Gbit/s
HDCP

Yes
Wall mountable

Yes
HDCP version

1.4
Connectivity technology

Wired
RJ-45 input ports

1
HDMI version

1.4
Remote (IR) input

1
Power source type

DC
Power consumption (typical)

9.5 W
Storage temperature (T-T)

-20 – 60 °C
Receiver dimensions (WxDxH)

169.2 x 181.8 x 42 mm
Quantity per pack

1 pc(s)

Brand

Aten
