ATEN 4-Port HDBaseT Input Board for VM1600 / VM3200

Part No:
VM7514
Full Product Specs
Price Locked for 30 Days:
Lock Added: N/A
exc VAT
£0.00
£0.00
inc VAT
Save 5% - First order discount - Any product - Any price*
Use Promo Code: FIRST5
*This promotion may only be used once, 5% discount is applied to your first order. Can not be used in-conjunction with any other offers. Not available if paying with PayPal.
Be quick, last one left in stock!
1 in stock.

4 port HDBaseT Input Board

Non-Returnable*

*This item is non-returnable and non-cancellable due to customisation or built to order.

Request info below or give us a call on 0203 617 7663
SKU: VM7514 Category:

Can't find what your looking for?

Our qualified I.T. experts are here & ready to help.

Contact us on 0203 617 7663 or email us directly
Aten

Related products

Description

The VM7514 4-Port HDBaseT Input Board offers an easy way route 4 HDBaseT transmitters connected to HDMI sources to 4 HDBaseT receivers connected to HDMI displays, and in combination with the ATEN Modular Matrix Switch provides the ability route up to 16 input and 16 output HDBaseT connections

– Compatible with the VM1600 and can be mixed with modular I/O boards of any type for optimum flexibility
– Bi-directional RS-232 channel – allows you to connect to serial terminals or serial devices, such as touch screens and barcode scanners
– HDBaseT Connectivity – extends 4 HDBaseT connections up to 100 meters via single Cat 5e/6 cable
– HDBaseT Anti-jamming – resists signal interference during video transmission using HDBaseT technology
– Bi-directional IR channel – IR transmission is processed one direction at a time
– Hot-swappable design for easy integration of I/O boards

Feature Feature Value
Audio (L/R) out 4
RJ-45 input ports 4
RS-232 ports 4
Material Metal
Product colour Black, Green
HDCP Yes
Supported graphics resolutions 4096 x 2160
Supported video modes 2160p
Bandwidth 340 MHz
Maximum resolution 4096 x 2160 pixels
Cable length 1000 m
Power consumption (typical) 24.5 W
Width 237 mm
Height 228 mm
Weight 990 g
Length 352 mm
Quantity per pack 1 pc(s)
Packaging content 1x VM7514 4-Port HDBaseT Input Board, 4x Terminal Block Connectors, 1x IR Transmitter, 1x IR Receiver,
1x User Instructions
Operating temperature (T-T) 0 – 40 °C
Storage temperature (T-T) -20 – 60 °C

Additional information

Audio (L/R) out

4
RS-232 ports

4
Product colour

Black, Green
Bandwidth

340 MHz
Cable length

1000 m
Width

237 mm
Weight

990 g
Quantity per pack

1 pc(s)
Operating temperature (T-T)

0 – 40 °C
RJ-45 input ports

4
Material

Metal
HDCP

Yes
Supported video modes

2160p
Maximum resolution

4096 x 2160 pixels
Power consumption (typical)

24.5 W
Height

228 mm
Length

352 mm
Packaging content

1x VM7514 4-Port HDBaseT Input Board, 4x Terminal Block Connectors, 1x IR Transmitter, 1x IR Receiver, 1x User Instructions
Storage temperature (T-T)

-20 – 60 °C

Brand

Aten
