ATEN 4 x 4 HDMI Audio/Video Matrix Switch + Videowall + Scaler and seamless switching

Part No:

VM5404H

Price Locked for 30 Days:
Lock Added: N/A
exc VAT
£0.00
£0.00
inc VAT
Full Product Specs
Save 5% - First order discount - Any product - Any price*
Use Promo Code: FIRST5
*This promotion may only be used once, 5% discount is applied to your first order. Can not be used in-conjunction with any other offers. Not available if paying with PayPal.

This item is currently unavailable for next day delivery, however you may still order this item as a back-order?.

VM5404H 4×4 HDMI Matrix Switch

Non-Returnable*

*This item is non-returnable and non-cancellable due to customisation or built to order.

Request info below or give us a call on 0203 617 7663
SKU: VM5404H Category:

Can't find what your looking for?

Our qualified I.T. experts are here & ready to help.

Contact us on 0203 617 7663 or email us directly
Aten

Related products

Description

The VM5404H 4 x 4 HDMI Matrix Switch is a distinct HDMI solution that offers an easy and affordable way to route any of 4 HDMI video sources to any of 4 HDMI displays, with a quick view of all port connections via the front panel LCD.
1x VM5404H 4 x 4 HDMI Matrix Switch with Scaler
1x LIN2-418K-E12G Power Cord
1x 2XRT-0106G IR Remote Control
1x 2XRT-0003G IR Receiver
1x Mounting Kit
1x User Instructions

Feature Feature Value
Product type Scaling matrix switcher
Data transfer rate 6.75 Gbit/s
Maximum pixel clock 225 MHz
HDCP Yes
HDCP version 1.4
3D Yes
Extended display identification data (EDID) Yes
Housing colour Black
Housing material Metal
Remote control included Yes
Built-in display Yes
HDMI input ports quantity 4
HDMI output ports quantity 4
RJ-45 input ports 1
RS-232 ports 1
Power consumption (max) 34.4 W
AC input voltage 100 – 240 V
AC input frequency 50 – 60 Hz
Input current 1 A
Operating temperature (T-T) 0 – 50 °C
Storage temperature (T-T) -20 – 60 °C
Operating relative humidity (H-H) 0 – 80%
Products per master (outer) case 1 pc(s)
Master (outer) case gross weight 6.04 kg
Master (outer) case length 515 mm
Master (outer) case width 338 mm
Master (outer) case height 155 mm
Master (outer) case net weight 4.32 kg
Harmonized System (HS) code 85299097
Width 262.3 mm
Depth 432.4 mm
Height 44 mm
Weight 4.32 kg
Package width 338 mm
Package depth 515 mm
Package height 155 mm
Package weight 6.04 kg
Cables included AC

Additional information

Product type

Scaling matrix switcher
Maximum pixel clock

225 MHz
HDCP version

1.4
Housing material

Metal
Built-in display

Yes
HDMI output ports quantity

4
RS-232 ports

1
AC input voltage

100 – 240 V
Input current

1 A
Storage temperature (T-T)

-20 – 60 °C
Master (outer) case length

515 mm
Master (outer) case height

155 mm
Harmonized System (HS) code

85299097
Depth

432.4 mm
Weight

4.32 kg
Package depth

515 mm
Package weight

6.04 kg
Data transfer rate

6.75 Gbit/s
HDCP

Yes
3D

Yes
Housing colour

Black
Remote control included

Yes
HDMI input ports quantity

4
RJ-45 input ports

1
Power consumption (max)

34.4 W
AC input frequency

50/60 Hz
Operating temperature (T-T)

0 – 50 °C
Master (outer) case width

338 mm
Width

262.3 mm
Height

44 mm
Package width

338 mm
Package height

155 mm
Cables included

AC

Brand

Aten
