ATEN 4X4 True 4K HDMI Martrix Switch

Part No:

VM0404HB

Price Locked for 30 Days:
Lock Added: N/A
exc VAT
£0.00
£0.00
inc VAT
Full Product Specs
Save 5% - First order discount - Any product - Any price*
Use Promo Code: FIRST5
*This promotion may only be used once, 5% discount is applied to your first order. Can not be used in-conjunction with any other offers. Not available if paying with PayPal.

This item is currently unavailable for next day delivery, however you may still order this item as a back-order?.

VM0404HB-AT-E 4×4 Matrix True 4K

Non-Returnable*

*This item is non-returnable and non-cancellable due to customisation or built to order.

Request info below or give us a call on 0203 617 7663
SKU: VM0404HB Category:

Can't find what your looking for?

Our qualified I.T. experts are here & ready to help.

Contact us on 0203 617 7663 or email us directly
Aten

Related products

Description

ATEN’s VM0404HB is a True 4K HDMI Matrix Switch series that offers an easy and affordable way to route any of 4 HDMI video sources to any of 4 HDMI displays. Featured with the superior video resolutions up to 4096 x 2160 @ 60Hz (4:4:4), the VM0404HB delivers robust signal routing and ultra-fast digital video switching, making it perfect for applications where routing of True 4K digital signals is required, such as event venues, digital classrooms, auditoriums, department stores, and more.
1x VM0404HB 4 x 4 True 4K HDMI Matrix Switch
1x LIN2-418K-E12G Power Cord
1x 2XRT-0106G IR Remote Control
1x 2XRT-0003G IR Receiver
1x Rack Mounting Kit
1x User Instructions

Feature Feature Value
Product type AV matrix switcher
Data transfer rate 18 Gbit/s
Maximum pixel clock 600 MHz
Maximum resolution 4096 x 2160 pixels
HDCP Yes
HDCP version 2.2
3D Yes
EDID management Yes
Housing colour Black
Housing material Metal
Rack capacity 1U
Remote control included Yes
Built-in display Yes
HDMI input ports quantity 4
HDMI output ports quantity 4
RJ-45 input ports 1
RS-232 ports 1
Power consumption (max) 17.8 W
AC input voltage 100 – 240 V
AC input frequency 50 – 60 Hz
Input current 1 A
Operating temperature (T-T) 0 – 40 °C
Storage temperature (T-T) -20 – 60 °C
Operating relative humidity (H-H) 0 – 80%
Products per master (outer) case 1 pc(s)
Master (outer) case gross weight 3.76 kg
Master (outer) case length 556 mm
Master (outer) case width 247 mm
Master (outer) case height 153 mm
Master (outer) case net weight 2.75 kg
Harmonized System (HS) code 85299097
Width 152.8 mm
Depth 437.2 mm
Height 44 mm
Weight 2.75 kg
Package width 247 mm
Package depth 556 mm
Package height 153 mm
Package weight 3.76 kg
Cables included AC
Mounting brackets included Yes

Additional information

Product type

AV matrix switcher
Maximum pixel clock

600 MHz
HDCP

Yes
3D

Yes
Housing colour

Black
Rack capacity

1U
Built-in display

Yes
HDMI output ports quantity

4
RS-232 ports

1
AC input voltage

100 – 240 V
Input current

1 A
Storage temperature (T-T)

-20 – 60 °C
Master (outer) case length

556 mm
Master (outer) case height

153 mm
Harmonized System (HS) code

85299097
Depth

437.2 mm
Weight

2.75 kg
Package depth

556 mm
Package weight

3.76 kg
Mounting brackets included

Yes
Data transfer rate

18 Gbit/s
Maximum resolution

4096 x 2160 pixels
HDCP version

2.2
EDID management

Yes
Housing material

Metal
Remote control included

Yes
HDMI input ports quantity

4
RJ-45 input ports

1
Power consumption (max)

17.8 W
AC input frequency

50/60 Hz
Operating temperature (T-T)

0 – 40 °C
Master (outer) case width

247 mm
Width

152.8 mm
Height

44 mm
Package width

247 mm
Package height

153 mm
Cables included

AC

Brand

Aten
