Description
The ATEN VS0801HB is designed for applications that require the routing of 8 sources to one compatible display device. It supports video resolutions up to True 4K (4096 x 2160 @ 60Hz 4:4:4), data rates up to 18 Gbps, 3D, Deep Color up to 12-bit, and HD lossless audio formats. The VS0801HB features Auto Switching modes for auto port selection. Multiple convenient control options include front panel pushbuttons, bi-directional RS-232, IR, and auto switch, allowing for easy integration.
1x VS0801HB 8-port True 4K HDMI Switch
1x 2XRT-0007G IR Remote Control Unit
1x 2XRT-0003G IR Receiver Cable
1x 0AD6-1F05-26EG Power Adapter
1x Rack Mounting Kit
1x User Instructions
| Feature |
Feature Value |
| Video port type |
HDMI |
| HDMI ports quantity |
8 |
| HDMI version |
2.0 |
| HDMI in |
8 |
| Number of HDMI outputs |
1 |
| RS-232 ports |
1 |
| DC-in jack |
Yes |
| Material |
Metal |
| Product colour |
Black |
| Consumer Electronics Control (CEC) support |
Yes |
| HDCP |
Yes |
| Maximum refresh rate |
60 Hz |
| Maximum operating distance |
3 m |
| Supported graphics resolutions |
1920 x 1080 (HD 1080), 3840 x 2160, 4096 x 2160 |
| Bandwidth |
18 Gbit/s |
| Bandwidth |
600 MHz |
| Maximum resolution |
4096 x 2160 pixels |
| 3D |
Yes |
| HD type |
4K Ultra HD |
| Input impedance |
100 Ω |
| Output impedance |
100 Ω |
| HDCP version |
2.2 |
| AC adapter input voltage |
5.3 V |
| Power consumption (typical) |
3.73 W |
| Width |
158.3 mm |
| Depth |
437.2 mm |
| Height |
44 mm |
| Weight |
2.42 kg |
| Package width |
116 mm |
| Package depth |
540 mm |
| Package height |
233 mm |
| Package weight |
2.87 kg |
| Mounting kit |
Yes |
| AC adapter included |
Yes |
| Operating temperature (T-T) |
0 – 40 °C |
| Storage temperature (T-T) |
-20 – 60 °C |
| Operating relative humidity (H-H) |
0 – 80% |
| Harmonized System (HS) code |
85176990 |
| Master (outer) case width |
375 mm |
| Master (outer) case length |
565 mm |
| Master (outer) case height |
258 mm |
| Master (outer) case gross weight |
9.5 kg |
| Products per master (outer) case |
3 pc(s) |
| Master (outer) case net weight |
7.26 kg |
