ATEN 4-Port HDMI Input Board for the VM1600 / VM3200
Part No:
VM7804
Save 5% - First order discount - Any product - Any price*
Use Promo Code: FIRST5
*This promotion may only be used once, 5% discount is applied to your first order. Can not be used in-conjunction with any other offers. Not available if paying with PayPal.
Be quick, last one left in stock!
1 in stock.
1 in stock.
VM7804 4-Port HDMI Input Board
Non-Returnable*
Description
The VM7804 4-Port HDMI Input Board is offers an easy way to route any of 4 audio/video sources to any of 4 displays, in combination with an ATEN Modular Matrix Switch.
1x VM7804 4-Port HDMI Input Board
4x JCNT-3301-105G Terminal Blocks
1x User Instructions
Feature | Feature Value |
---|---|
Product type | Input board |
Product colour | Black, Green |
Material | Metal |
HDMI ports quantity | 4 |
Power consumption (typical) | 7 W |
Width | 238 mm |
Depth | 352 mm |
Height | 23.3 mm |
Weight | 540 g |
Package width | 285 mm |
Package depth | 426 mm |
Package height | 57 mm |
Package weight | 920 g |
Operating temperature (T-T) | 0 – 40 °C |
Operating relative humidity (H-H) | 0 – 80% |
Storage temperature (T-T) | -20 – 60 °C |
Products per master (outer) case | 2 pc(s) |
Master (outer) case gross weight | 2.27 kg |
Master (outer) case length | 440 mm |
Master (outer) case width | 300 mm |
Master (outer) case height | 138 mm |
Master (outer) case net weight | 1.08 kg |
Additional information
Product type | Input board |
---|---|
Material | Metal |
Power consumption (typical) | 7 W |
Depth | 352 mm |
Weight | 540 g |
Package depth | 426 mm |
Package weight | 920 g |
Master (outer) case length | 440 mm |
Master (outer) case height | 138 mm |
Product colour | Black, Green |
HDMI ports quantity | 4 |
Width | 238 mm |
Height | 23.3 mm |
Package width | 285 mm |
Package height | 57 mm |
Operating temperature (T-T) | 0 – 40 °C |
Storage temperature (T-T) | -20 – 60 °C |
Master (outer) case width | 300 mm |
