ATEN HDBaseT SF/UTP CAT 6 Cable; 305M, Frequency up to 400 MHz

Part No:
2L-2910
Full Product Specs
Price Locked for 30 Days:
Lock Added: N/A
exc VAT
£0.00
£0.00
inc VAT
Save 5% - First order discount - Any product - Any price*
Use Promo Code: FIRST5
*This promotion may only be used once, 5% discount is applied to your first order. Can not be used in-conjunction with any other offers. Not available if paying with PayPal.

This item is currently unavailable for next day delivery, however you may still order this item as a back-order?

HDBaseT SF/UTP Cat 6 cable 305 m/ 1000 ft

Non-Returnable*

*This item is non-returnable and non-cancellable due to customisation or built to order.

Request info below or give us a call on 0203 617 7663
SKU: 2L-2910 Category:

Can't find what your looking for?

Our qualified I.T. experts are here & ready to help.

Contact us on 0203 617 7663 or email us directly
Aten

Related products

Description

The 2L-2910 is a twisted pair cable engineered for optimum signal transmission at resolutions up to 4K including digital and analogue data, audio, and video applications. The cable supports sweep frequency up to 400 MHz and has been verified to meet performance requirements set by the HDBaseT Alliance.

The 2L-2910 supports long distance connections while safeguarding transmission quality. The outer metal layer and the braid protect signal transmissions from electromagnetic interference and reduce the impact caused by electrical noise.

The 2L-2910 utilizes SF/UTP design with four unshielded 23 AWG twisted pair conductors. Among the four unshielded twisted pair conductors, there is one cross filler to reduce cross talk. Most importantly, the cable meets the requirements set by ANSI/ TIA-568-C.2 (2009) ensuring high performance in electrical transmission.

Feature Feature Value
Cable length 305 m
Cable standard Cat6
Cable shielding SF/UTP (S-FTP)
Connector 1 No
Connector 2 No
Product colour Blue
Connector 1 gender No
Connector 2 gender No
Connector contacts plating Copper
Connector shielding Yes
Connector shield material Aluminium
Jacket material Polyvinyl chloride (PVC)
Cable shape Round
Conductor type Stranded
Conductor material Copper
Cable type Crossover cable
Networking standards IEEE 802.3af, IEEE 802.3at
AWG wire size 23
Frequency 400 MHz
Operating temperature (T-T) -20 – 60 °C
Weight 19.6 kg
Quantity per pack 1 pc(s)
Package weight 20.4 kg
Package type Wooden drum
Harmonized System (HS) code 84733080
Master (outer) case net weight 19.6 kg
Master (outer) case width 408 mm
Master (outer) case length 408 mm
Master (outer) case gross weight 20.4 kg
Master (outer) case height 288 mm
Products per master (outer) case 1 pc(s)

Additional information

Cable length

305 m
Cable shielding

SF/UTP (S-FTP)
Connector 2

No
Connector 1 gender

No
Connector contacts plating

Copper
Connector shield material

Aluminium
Cable shape

Round
Conductor material

Copper
Networking standards

IEEE 802.3af, IEEE 802.3at
Frequency

400 MHz
Weight

19.6 kg
Package weight

20.4 kg
Harmonized System (HS) code

84733080
Master (outer) case width

408 mm
Cable standard

Cat6
Connector 1

No
Product colour

Blue
Connector 2 gender

No
Connector shielding

Yes
Jacket material

Polyvinyl chloride (PVC)
Conductor type

Stranded
Cable type

Crossover cable
AWG wire size

23
Operating temperature (T-T)

-20 – 60 °C
Quantity per pack

1 pc(s)
Package type

Wooden drum
Master (outer) case length

408 mm
Master (outer) case height

288 mm

Brand

Aten
