Allied Telesis MMCR18 network equipment chassis
Lock Added: N/A
This item is currently unavailable for next day delivery, however you may still order this item as a back-order?
Allied Telesis Media Conversion Rack-Mount Chassis – Modular expansion base – 2U – TAA Compliant
Related products
Description
Media converter flexibility
The Allied Telesis MMCR18 is a two rack unit high chassis, which enables network managers to use up to 18 MMC series media converters in a standard 19 inch rack. For redundancy, it can be powered with either one or two Power Supply Units (PSUs).
Power options
The MMCR18 Chassis can be powered with either an AC or DC power supply, eliminating the need for multiple power connections. Allied Telesis also offers an optional hot swappable PSU to eliminate network downtime. The unit saves space in the wiring closet, and minimizes the number of power connections required. Single-unit media converters can be removed from the MMCR18 and deployed individually to accommodate network modifications.
By incorporating a backplane with 18 different power entry modules integrated with the printed circuit board, power is equally distributed among all media converters—whether
using one or two PSUs.
Rack-mount design
Designed with a simple mounting system, each individual media converter is plugged into the back plane and secured with the included mounting rail.The rack-mount chassis includes
six status LEDs on the front panel indicating power, temperature, fan and fault status.
| Feature | Feature Value |
|---|---|
| Rack mounting | Yes |
| LED indicators | Yes |
| Material | Metal |
| Number of slots | 18 |
| Operating temperature (T-T) | 0 – 50 °C |
| Storage temperature (T-T) | -20 – 70 °C |
| Operating relative humidity (H-H) | 5 – 80% |
| Storage relative humidity (H-H) | 5 – 80% |
| Safety | UL, CSA, TUV, IEC 825-1, CE compliant |
| Certification | FCC Class A, IC Class A |
| Width | 440 mm |
| Depth | 255 mm |
| Height | 87 mm |
| Weight | 4.3 kg |
