Juniper MX10003 network equipment chassis 3U Grey
Lock Added: N/A
This item is currently unavailable for next day delivery, however you may still order this item as a back-order?
MX10003-BASE
Related products
Description
The service-centric MX10003 Universal Routing Platform is a space- and power-optimized routing platform that helps service providers and cloud operators address long-term traffic, subscriber, and services growth. It provides ultra-high density and throughput in only three rack units (3 U).
With 2.4 Tbps of throughput, the MX10003 supports up to 144 10GbE interfaces, 36 40GbE interfaces, or 24 100GbE interfaces in a single chassis. Its high performance and density make it ideal for a wide range of business and residential services, as well as mobile and cloud applications. The MX10003 can be deployed for business VPNs, next-generation broadband multiplay, high-volume Internet, Metro Ethernet services, and data center internetworking.
The MX10003 offers standards-based and hardware-accelerated CUPS user plane capabilities with 3GPP-Sx interoperability, delivering ultra-efficient mobile 5G performance at scale. Additionally, the MX10003 supports sophisticated timing, MACsec encryption, and advanced automation and telemetry capabilities that lay the groundwork for autonomous networks.
The MX10003 also delivers the highest levels of network availability with resiliency features that include control plane redundancy and N+1 power supply module redundancy. Additionally, Virtual Chassis technology supports chassis-level redundancy while allowing users to manage two routers as a single element.
| Feature | Feature Value |
|---|---|
| Rack mounting | Y |
| Rack capacity | 3U |
| Cooling type | Active |
| Product colour | Grey |
| Number of fans | 4 fan(s) |
| Number of power supply units | 4 |
| Width | 482.6 mm |
| Depth | 762 mm |
| Height | 132.5 mm |
Additional information
| Rack mounting | Y |
|---|---|
| Cooling type | Active |
| Number of fans | 4 fan(s) |
| Width | 482.6 mm |
| Height | 132.5 mm |
| Rack capacity | 3U |
| Product colour | Grey |
| Depth | 762 mm |
