Broadcom MegaRAID 9670W-16i RAID controller PCI Express

Part No:
05-50123-00
Full Product Specs
Price Locked for 30 Days:
Lock Added: N/A
exc VAT
£937.58
£1,125.10
inc VAT
Save 5% - First order discount - Any product - Any price*
Use Promo Code: FIRST5
*This promotion may only be used once, 5% discount is applied to your first order. Can not be used in-conjunction with any other offers.
33 still available

Broadcom MegaRAID 9670-24i – Storage controller (RAID) – 24 Channel – SATA 6Gb/s / SAS 24Gb/s / PCIe 4.0 (NVMe) – RAID 0, 1, 5, 6, 10, 50, 60 – PCIe 4.0 x8

33 in stock (can be backordered)

Safe & Secure shopping

SKU: 05-50123-00 Category:

Can't find what your looking for?

Our qualified I.T. experts are here & ready to help.

Contact us on 0203 617 7663 or email us directly

Related products

Description

The MegaRAID 9600 series is the third generation of Tri-Mode x8 and x16 NVMe/SAS/SATA adapters. Designed to deliver the best possible performance for NVMe SSD-based storage systems, the 9600 family delivers 2x the bandwidth, over 4x the IOPs, 25x reduction in write latency and 60x increase in performance during rebuilds over the previous generation.

The MegaRAID 9670-24i adapter, based on the SAS4124 RAID-on-Chip (RoC), integrates a 2×72-bit high-speed DDR memory interface delivering faster speeds at 3,200 MT/s and more than 4x increase in RAID5 Random Write IOPs over previous generation adapters. Gain the most flexibility out of your storage controller by direct connecting up to 24 Gen 4.0 NVMe, 24G SAS or SATA devices.

Feature Feature Value
Supported storage drive interfaces SAS, Serial ATA
Host interface PCI Express x8
PCI Express slots version 4.0
Internal SAS ports 3
RAID levels 0, 1, 5, 6, 10, 50, 60
Data transfer rate 6 Gbit/s
Form factor MD2
SSD support Y
S.M.A.R.T. support Y
Number of devices supported 240
Channels quantity 24 channels
Mean time between failures (MTBF) 3000000 h
Certification Australia/New Zealand RCM (AS/NZS CISPR 32; CISPR 32:2015, Class A; AS/NZS CISPR 32:2015, Class A), Canada EMC (ICES-003:2016 Issue 6: 2016, Class A; CAN/CSA CISPR 22-10; CISPR 22:2008), Europe (CE) (EN 55024, EN 55032, EN 55035; EN 55032:2015 +AC:2016, Class A; EN 55024:2010 +A1:2015; EN 55035:2017 +A11:2020), Korea (KN32/KN35), Taiwan BSMI (CNS 13438; CNS15663), USA/Canada Safety (UL Listed) (UL 62368-1, Second Edition; CAN/CSA C22.2 No. 62368-1-14), USA/Canada (FCC) (47 CFR FCC Part 15, Subpart B, Class A; ANSI C63.4:2014; CISPR 32:2008) CB (IEC 62368-1:2014 (Second edition); EN 62368-1:2014+A11: 2017), Japan (V-3/2015.04, Class A; V-4/2012.04; VCCI-CISPR 32:2016; CISPR 32:2015), Morocco (CMIM) (EN 55024, EN 55032, EN 55035; EN 55032:2015 +AC:2016, Class A; EN 55024:2010 +A1:2015; EN 55035:2017 +A11:2020)
Power consumption (typical) 24 W
Sustainability certificates RoHS, WEEE
Windows operating systems supported Y
Linux operating systems supported Y
Server operating systems supported SUSE Linux Enterprise Server
Operating temperature (T-T) 0 – 55 °C
Operating relative humidity (H-H) 5 – 90%
Width 155.6 mm
Depth 111.1 mm
Other operating systems supported VMware vSphere ESXi

Additional information

PCI Express slots version

4.0
RAID levels

0, 1, 5, 6, 10, 50, 60
Form factor

MD2
S.M.A.R.T. support

Y
Channels quantity

24 channels
Certification
Sustainability certificates

RoHS, WEEE
Operating temperature (T-T)

0 – 55 °C
Width

155.6 mm
Host interface

PCI Express x8
Internal SAS ports

3
Data transfer rate

6 Gbit/s
SSD support

Y
Number of devices supported

240
Power consumption (typical)

24 W
Depth

111.1 mm
