| Processor family |
Intel® Core™ i7 |
| Processor cores |
4 |
| Processor socket |
LGA 1151 (Socket H4) |
| Processor lithography |
14 nm |
| Box |
N |
| Cooler included |
N |
| Processor manufacturer |
Intel |
| Processor model |
i7-6700 |
| Processor base frequency |
3.4 GHz |
| Processor operating modes |
64-bit |
| Processor generation |
6th gen Intel® Core™ i7 |
| Component for |
PC |
| Processor series |
Intel Core i7-6700 Desktop series |
| Processor threads |
8 |
| System bus rate |
8 GT/s |
| Processor boost frequency |
4 GHz |
| Processor cache |
8 MB |
| Processor cache type |
Smart Cache |
| Thermal Design Power (TDP) |
65 W |
| Compatible chipsets |
Intel® B150, Intel® H110, Intel® H170, Intel Q150, Intel® Q170, Intel® Z170 |
| Stepping |
R0 |
| Bus type |
DMI3 |
| Memory bandwidth supported by processor (max) |
34.1 GB/s |
| Processor codename |
Skylake |
| Processor code |
SR2L2 |
| Processor ARK ID |
88196 |
| Memory channels |
Dual-channel |
| Maximum internal memory supported by processor |
64 GB |
| Memory types supported by processor |
DDR4-SDRAM, DDR3L-SDRAM |
| Memory clock speeds supported by processor |
1333,1600,1866,2133 MHz |
| Memory voltage supported by processor |
1.35 V |
| ECC |
N |
| On-board graphics card |
Y |
| On-board graphics card model |
Intel® HD Graphics 530 |
| Maximum on-board graphics card memory |
64 GB |
| On-board graphics card outputs supported |
Embedded DisplayPort (eDP), DisplayPort, HDMI, DVI |
| On-board graphics card base frequency |
350 MHz |
| On-board graphics card dynamic frequency (max) |
1150 MHz |
| Number of displays supported (on-board graphics) |
3 |
| On-board graphics card 4K support |
Y |
| On-board graphics card DirectX version |
12.0 |
| On-board graphics card OpenGL version |
4.5 |
| On-board graphics card maximum resolution (DisplayPort) |
4096 x 2304 pixels |
| On-board graphics card maximum resolution (eDP – Integrated Flat Panel) |
4096 x 2304 pixels |
| On-board graphics card maximum resolution (HDMI) |
4096 x 2304 pixels |
| On-board graphics card refresh rate at maximum resolution (DisplayPort) |
60 Hz |
| On-board graphics card refresh rate at maximum resolution (eDP – Integrated Flat Panel) |
60 Hz |
| On-board graphics card refresh rate at maximum resolution (HDMI) |
24 Hz |
| On-board graphics card ID |
0x1912 |
| Execute Disable Bit |
Y |
| Idle States |
Y |
| Thermal Monitoring Technologies |
Y |
| Market segment |
Desktop |
| Maximum number of PCI Express lanes |
16 |
| PCI Express slots version |
3.0 |
| PCI Express configurations |
1×16, 2×8, 1×8+2×4 |
| Supported instruction sets |
SSE4.1, SSE4.2, AVX 2.0 |
| Scalability |
1S |
| CPU configuration (max) |
1 |
| Embedded options available |
Y |
| Graphics & IMC lithography |
14 nm |
| Thermal solution specification |
PCG 2015C |
| PCI Express CEM revision |
3.0 |
| Harmonized System (HS) code |
8542310001 |
| Export Control Classification Number (ECCN) |
5A992C |
| Commodity Classification Automated Tracking System (CCATS) |
G077159 |
| Intel® Hyper Threading Technology (Intel® HT Technology) |
Y |
| Intel® Identity Protection Technology (Intel® IPT) |
Y |
| Intel® Turbo Boost Technology |
2.0 |
| Intel® Quick Sync Video Technology |
Y |
| Intel® InTru™ 3D Technology |
Y |
| Intel® Wireless Display (Intel® WiDi) |
Y |
| Intel® Clear Video HD Technology (Intel® CVT HD) |
Y |
| Intel® Insider™ |
Y |
| Intel® AES New Instructions (Intel® AES-NI) |
Y |
| Enhanced Intel SpeedStep Technology |
Y |
| Intel Trusted Execution Technology |
Y |
| Intel® Memory Protection Extensions (Intel® MPX) |
Y |
| Intel® Turbo Boost Technology 2.0 frequency |
4 GHz |
| Intel® Transactional Synchronization Extensions |
Y |
| Intel Enhanced Halt State |
Y |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) |
Y |
| Intel VT-x with Extended Page Tables (EPT) |
Y |
| Intel® Secure Key |
Y |
| Intel TSX-NI |
Y |
| Intel Stable Image Platform Program (SIPP) |
Y |
| Intel® OS Guard |
Y |
| Intel® Small Business Advantage (Intel® SBA) |
Y |
| Intel Clear Video Technology |
Y |
| Intel Software Guard Extensions (Intel SGX) |
Y |
| Intel 64 |
Y |
| Intel Identity Protection Technology version |
1.00 |
| Intel Secure Key Technology version |
1.00 |
| Intel Small Business Advantage (SBA) version |
1.00 |
| Intel Stable Image Platform Program (SIPP) version |
1.00 |
| Intel Virtualization Technology (VT-x) |
Y |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Y |
| Intel TSX-NI version |
1.00 |
| Conflict-Free processor |
Y |
| Intel® Optane™ Memory Ready |
N |
| Intel® Boot Guard |
Y |
| Intel® vPro™ Platform Eligibility |
Y |
| Tcase |
71 °C |
| Processor cache |
8192 KB |
| Product type |
Processor |
| Supported memory types |
DDR4-SDRAM, DDR3L-SDRAM |
| Maximum graphics card memory |
64 GB |
| Package type |
Retail box |
| Processor package size |
37.5 x 37.5 mm |
| Maximum internal memory |
64 GB |
| Maximum internal memory |
65536 MB |
| Video decoding |
Y |
| Generation |
6th Generation |
| Bus bandwidth |
8 |
| Bus type units |
GT/s |
| Launch date |
Q3’15 |
| Maximum resolution & refresh rate (DisplayPort) |
4096×2304@60Hz |
| Maximum resolution & refresh rate (HDMI) |
4096×2304@24Hz |
| Maximum resolution & refresh rate (Integrated Flat Panel) |
4096×2304@60Hz |
| Maximum resolution & refresh rate (VGA) |
N/A |
| Number of graphics cores |
2 |
| Status |
Launched |
| Maximum memory |
64 GB |
| Processor brand name |
Intel Core i7
Intel Core i7 Processor |
| Last change |
63903513 |
| Maximum resolution (WiDi) |
1080p |
| Product family |
6th Generation Intel Core i7 Processors |
| Bus speed |
8 GT/s |
| Processor ID |
0x1912 |
| Graphics output |
eDP/DP/HDMI/DVI |
