Description
The ATEN VK320 is an 8” Touch Panel featuring capacitive multi-touch IPS-LCD screen with a narrow bezel. Natively installed with the ATEN Control System app, the touch panel is compatible with ATEN Control Boxes and Control Pads.
The VK320 supports Power over Ethernet (PoE), which allows power and data to be carried over a single Ethernet cable to the touch panel, making it perfect for applications that require solid and wired connections.
The Touch Panel VK320 features an in-wall design and a sophisticated touch panel that comes complete with an 86-type junction box, ensuring a versatile and efficient solution. The VK320 is also perfectly suitable for the smaller and compact scenarios such as digital podiums or lecterns. It is worth noting that the VK320’s mounting plate is compatible with standard decorator-style, 1-gang junction boxes of the US, EU, and MK type; it is also compatible with VK102 Tabletop Kit that supports desk mounting and wall mounting to meet versatile installation needs. The uniform equilateral design is suitable for flexible placement in either horizontal or vertical orientation.
| Feature | Feature Value |
|---|---|
| Display diagonal | 20.3 cm (8″) |
| Display resolution | 1280 x 800 pixels |
| Display technology | IPS |
| Aspect ratio | 16:10 |
| Viewing angle | 170° |
| Display brightness | 300 cd/m² |
| Contrast ratio (typical) | 800:1 |
| Touchscreen | Yes |
| Touchscreen technology | Capacitive |
| Housing colour | Black |
| Housing material | Plastic |
| Built-in processor | Yes |
| Processor cores | 4 |
| RAM capacity | 2 GB |
| Storage capacity | 32000 MB |
| Ethernet LAN | Yes |
| Networking standards | IEEE 802.3af |
| RJ-45 ports quantity | 1 |
| Power source type | DC, PoE |
| Power consumption (max) | 12 W |
| Width | 124.6 mm |
| Depth | 200.1 mm |
| Height | 37.7 mm |
| Weight | 480 g |
| Package width | 150 mm |
| Package depth | 240 mm |
| Package height | 67 mm |
| Package weight | 700 g |
| Operating relative humidity (H-H) | 10 – 75% |
| Operating temperature (T-T) | 0 – 40 °C |
| Storage temperature (T-T) | -10 – 55 °C |
Additional information
| Display diagonal | 20.3 cm (8") |
|---|---|
| Display technology | IPS |
| Viewing angle | 170° |
| Contrast ratio (typical) | 800:1 |
| Touchscreen technology | Capacitive |
| Housing material | Plastic |
| Processor cores | 4 |
| Storage capacity | 32000 MB |
| Networking standards | IEEE 802.3af |
| Power source type | DC, PoE |
| Width | 124.6 mm |
| Height | 37.7 mm |
| Package width | 150 mm |
| Package height | 67 mm |
| Storage temperature (T-T) | -10 – 55 °C |
| Display resolution | 1280 x 800 pixels |
| Aspect ratio | 16:10 |
| Display brightness | 300 cd/m² |
| Touchscreen | Yes |
| Housing colour | Black |
| Built-in processor | Yes |
| RAM capacity | 2 GB |
| Ethernet LAN | Yes |
| RJ-45 ports quantity | 1 |
| Power consumption (max) | 12 W |
| Depth | 200.1 mm |
| Weight | 480 g |
| Package depth | 240 mm |
| Package weight | 700 g |
| Operating temperature (T-T) | 0 – 40 °C |
