Description
Energy-saving, ergonomic, reliable: the EV2460 offers a wide range of connection options thanks to DisplayPort, HDMI, DVI-D and D-Sub signal inputs as well as four USB downstream ports. The EV2460 caters for sophisticated computer workstations with the highest demands. Image quality and ergonomics are equally convincing. With a resolution of 1920 x 1080 pixels, an IPS LCD panel with an antireflective surface, this display excels at detailed, crystal-clear image reproduction.
| Feature |
Feature Value |
| Display diagonal |
60.5 cm (23.8″) |
| Display resolution |
1920 x 1080 pixels |
| Native aspect ratio |
16:9 |
| Display technology |
LED |
| Touchscreen |
N |
| HD type |
Full HD |
| Panel type |
IPS |
| Screen shape |
Flat |
| Contrast ratio (typical) |
1000:1 |
| Maximum refresh rate |
60 Hz |
| Display number of colours |
16.78 million colours |
| Display brightness (typical) |
250 cd/m² |
| Response time |
5 ms |
| Supported graphics resolutions |
1920 x 1080 (HD 1080) |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Pixel pitch |
0.2745 x 0.2745 mm |
| Pixel density |
93 ppi |
| Horizontal scan range |
31 – 68 kHz |
| Vertical scan range |
59 – 61 Hz |
| Viewable size, horizontal |
52.7 cm |
| Viewable size, vertical |
29.6 cm |
| Digital horizontal frequency |
31 – 68 kHz |
| Digital vertical frequency |
51 – 59 Hz |
| RGB colour space |
sRGB |
| 3D |
N |
| Separate H/V sync |
Y |
| NVIDIA G-SYNC |
N |
| AMD FreeSync |
N |
| Flicker-free technology |
Y |
| Low Blue Light technology |
Y |
| Built-in speaker(s) |
Y |
| Built-in camera |
N |
| Number of speakers |
2 |
| RMS rated power |
2 W |
| Market positioning |
Home |
| Product colour |
Black |
| Certification |
CE, CB, TCO certified 8.0, EPA Energy Star, TÜV / GS, TÜV / Ergonomics (including ISO 9241-307), TÜV / Low blue light content, TÜV / Flicker Free, EPEAT 2018 (US), cTÜVus, TÜV / S , EAC, FCC-B, CAN ICES-3 (B), VCCI-B, CCC, RoHS, China RoHS, WEEE |
| Built-in USB hub |
Y |
| HDMI |
Y |
| Headphone out |
Y |
| USB hub version |
3.0 |
| USB upstream port type |
USB Type-B |
| Number of upstream ports |
1 |
| USB Type-A downstream ports quantity |
4 |
| VGA (D-Sub) ports quantity |
1 |
| DVI port |
Y |
| DVI-D ports quantity |
1 |
| HDMI ports quantity |
1 |
| DisplayPorts quantity |
1 |
| Audio input |
Y |
| Headphone outputs |
1 |
| Headphone connectivity |
3.5 mm |
| HDCP |
Y |
| VESA mounting |
Y |
| Cable lock slot |
Y |
| Height adjustment |
Y |
| Panel mounting interface |
100 x 100 mm |
| Cable lock slot type |
Kensington |
| Height adjustment |
14 cm |
| Pivot |
Y |
| Pivot angle |
-90 – 90° |
| Swivelling |
Y |
| Swivel angle range |
0 – 344° |
| Tilt angle range |
-5 – 35° |
| On Screen Display (OSD) |
Y |
| On Screen Display (OSD) languages |
Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Swedish |
| Tilt adjustment |
Y |
| Energy efficiency class (SDR) |
B |
| Energy consumption (SDR) per 1000 hours |
9 kWh |
| Power consumption (typical) |
9 W |
| Power consumption (standby) |
0.5 W |
| AC input voltage |
100 – 240 V |
| AC input frequency |
50/60 Hz |
| Energy efficiency scale |
A to G |
| Operating temperature (T-T) |
5 – 35 °C |
| Operating relative humidity (H-H) |
20 – 80% |
| Cables included |
AC, DisplayPort, USB |
| Quick start guide |
Y |
| Width (with stand) |
537.8 mm |
| Depth (with stand) |
233 mm |
| Height (with stand) |
333.6 mm |
| Weight (with stand) |
5.9 kg |
| Width (without stand) |
53.8 cm |
| Depth (without stand) |
5.36 cm |
| Height (without stand) |
35 cm |
| Weight (without stand) |
3.8 kg |
| Sustainability certificates |
RoHS, ENERGY STAR |
| Harmonized System (HS) code |
85285210 |
| On/off switch |
Y |
| TV tuner integrated |
N |
